Place of Origin: | China |
Brand Name: | Brando |
Certification: | ISO、CE |
Model Number: | CA20T |
Minimum Order Quantity: | 1Pcs,Sample Available |
---|---|
Price: | negotiation |
Packaging Details: | inner boxes,cartons,pallets |
Delivery Time: | 7 working days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 100000pcs per month |
Material Of Body: | Aluminum | Specification: | 3/4 Inch |
---|---|---|---|
Media: | Air | Structure: | Angle |
Voltage: | AC110V/AC220V/DC24V | Power: | Pneumatic |
Highlight: | solenoid pulse valve,pulse solenoid valve |
3/4 Inch T-Type 90Degree Right Angle,Aluminum Pneumatic Pulse Valve
The pulse injection performance of the plateau electromagnetic pulse valve is more powerful. Double stud connection and flanged inlet/slide outlet connection in three models make the maintenance of pulse valve more convenient and fast.
Composition: pulse valve is composed of solenoid valve, small valve body, large valve body, small diaphragm, spring, large diaphragm, valve body material is alloy aluminum
Body: Aluminium (diecast)
Ferrule: 304 SS
Armature: 430FR SS
Seals: Nitrile or Viton (reinforced)
Spring: 304 SS
Screws: 302 SS
Description of the CA20T
CA20T | |
Working Pressure | 0.3-0.8MPa |
Environment Temperature | ﹣5-55℃ |
Relative Humidity | <85% |
Use Medium | Dry Clean Compressed Air |
Electric Pressure | 110V 220V AC,24V DC |
Diaphragm Life | Injection of 1million or more |
Nominal Diameter | φ20 |
The drawings of CA20T
We can provide most suitable packages for products
The pakages ensure the sealing and safety
Working Principle of Pulse Valve:
Plateau unloading electromagnetic pulse valve is in accordance with the electrical control valve body hole opening and closing of the valve body when unloading valve cavity pressure gas emissions, after before the valve cavity pressure gas by Yin on the diaphragm pressure orifice throttling, diaphragm is lifted, the injection pulse valve. The valve body when they stop unloading pressure gas by damping hole quickly after full of valve cavity, the difference between the two sides because the diaphragm on the valve body stress area, after the valve cavity, the gas forces, shutoff valve diaphragm can reliable injection, pulse valve stops blowing.
Electrical signal is millisecond timing, pulse valve opened at the moment, a strong impact airflow, so as to achieve instant injection.
Operating conditions:
1) ac and dc solenoid valves are selected according to the type of power supply. Generally speaking, ac power supply is convenient to access.
2) corrosion resistance shall be preferred according to safety requirements when used in corrosive or explosive environment.
3) if the environment space is limited, please choose the multi-function solenoid valve, because it saves the bypass and three-handed valve and is convenient for online maintenance.
4) as far as possible, AC220V and DC24V are preferred for voltage specifications.
5) waterproof solenoid valve should be selected for occasions with high relative humidity in the environment and raindrops.
6) rated current and consumed power shall be selected according to the power supply capacity. Attention should be paid to the high VA value during ac starting, and the indirect guided solenoid valve should be preferred when the capacity is insufficient.
The Pulse Valve Role:
Control the oil pressure in the oil circuit. It is generally installed in the main oil circuit or the back pressure oil circuit of the shock absorber to reduce the oil pressure impact when shifting and locking and unlocking, so as to keep the equipment running smoothly.
Any Inquiry will be appreciated!
