| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE, ISO |
| Model Number: | CA45DD |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, PayPal |
| Supply Ability: | 10000 pcs per month |
| Port Size: | 1 1/2 Inch | Valve Structure:: | Dresser Nut, Right Angle |
|---|---|---|---|
| Diaphragm Material: | NBR, Viton | Working Pressure Range: | 0.35 To 0.85 MPa |
| Coil Voltages: | DC24V, AC110V, AC220V | Valve Series: | DD Series |
| Highlight: | Pulse Solenoid Valve For Dusting Removal,CA45DD Pulse Jet Valve,Pulse Diaphragm Valve 1 1/2 Inches |
||
Goyen Type CA45DD 1 1/2'' Pulse Jet Valve Dresser Nut DD Series
The Goyen Type CA45DD is a dresser nut pulse jet valve is with double head inlet and outlet air port. High performance diaphragm valve with dresser nut ports. Available with integral pilot or as remotely piloted valve. Outlet at 90° to inlet. Dust collector applications, in particular for reverse pulse jet filter cleaning and its variations, including bag filters, cartridge filters and envelope filters, ceramic filters and sintered metal fibre filters.
Technical Data of DD Series Pulse Jet Valves:
|
Model No
|
CA20DD
|
CA25DD
|
CA45DD
|
|
Port Size
|
3/4''
|
1''
|
1 1/2''
|
|
Pipe Connection
|
Dresser Nut
|
||
|
Diaphragm Number
|
1
|
1
|
2
|
|
Working Pressure Range
|
0.35 to 0.85 MPa (5 to 125 PSI)
|
||
|
Diaphragm Material
|
NBR, FKM, EPDM
|
||
|
Valve Body Material
|
Aluminum Alloy
|
||
Main Dimension of CA45DD Solenoid Pulse Jet Valve:
Ordering Code of DD Series Pulse Jet Valve:
Video of CA45DD Pulse Jet Valve:
More Goyen Type Pulse Jet Valves for you to choose:
|
|
|
|
| T Series | DD Series | FS Series | MM Series |
|
|
|
|
| RCA Series | Solenoid Coil | Solenoid Armature | Diaphragm |
