RO Water Purifier Solenoid Valve

RO Water Purifier Solenoid Valve

  • RO Water Purifier Solenoid Valve
  • RO Water Purifier Solenoid Valve
RO Water Purifier Solenoid Valve
Product Details:
Place of Origin: Ningbo, China
Brand Name: Brando
Certification: CE, ISO9001
Model Number: BPV05
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Inner box, then loaded into carton, then packed by pallet for sea shipment
Delivery Time: 7 working days after receive payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200000pcs per month
Contact Now
Detailed Product Description
Product Name: RO Solenoid Valve Operation: Direct Acting
Orifice Size: 1 To 5mm Port Size: 1/8'', 1/4'', 3/8''
Connection: Female Thread, Push In Fast Fit Body Material: PP, POM
Medium: Water, Air, Oil Working Pressure: 0 To 120psi
Seal Material: NBR, FKM, EPDM Voltage: 12VDC, 24VDC, 36VDC, 48VDC
High Light:

Solenoid Valve For RO

,

Solenoid Valve For RO Water Purifier

,

RO Solenoid Valve 24VDC

RO Water Purifier Solenoid Valve



The BPV is a Solenoid Valve for RO Water Purifier Systems. This solenoid valve is a direct acting normally closed valve that isolates the tap water and opens when the system is actuated or in FLUSH mode. This is a 2/2 valve which means it has 2 ports and 2 flow positions. Put simply, this valve either blocks or opens water flow from 1 inlet to 1 outlet. They have prewired connections that make installation, maintenance, and control simple.



Water purification systems can help to eliminate contaminants that can make you sick or affect the taste or feel of your water supply.In a Reverse Osmosis (RO) water purifying system, reverse osmosis is utilized to dissolve inorganic solids (such as salts) and removes them from a solution (such as water). This is achieved by using the household water pressure to push tap water through a semi permeable membrane. The membrane (which is about as thick as cellophane) allows only the water to pass through, not the impurities or contaminates. These impurities and contaminates are flushed down the drain. These systems use a lot of water, but they do remove all microbes that cause disease and a lot of chemicals. This is an extremely effective system for purifying water.



Dimension & Data of RO Solenoid Valves:

RO Water Purifier Solenoid Valve 0

Model

 BPV09

Medium
Water, Air, Oil, etc
Medium Temperature Range
-10 to +80℃
Body Material
PP, POM
Working Pressure Range
0-8bar
Conection Type
Female Thread
Port Size
1/4'' NPT
Voltage
12VDC, 24VDC, 36VDC, 48VDC
Seal Material
NBR, FKM, EPDM



RO Water Purifier Solenoid Valve 1

Model
BPV05
Medium
Water, Air, Oil, etc
Medium Temperature Range
-10 to +80℃
Body Material
PP, POM
Working Pressure Range
0-8bar
Conection Type
Fast Fitting,
Tube OD 6.35mm
Voltage
12VDC, 24VDC, 36VDC, 48VDC
Seal Material
NBR, FKM, EPDM


Applications for RO Solenoid Valves:

1. Point of Use (POU) Drinking Water Systems
2. Home RO Systems
3. Commercial RO Systems
4. Point of Entry (POE) Water Filtration Systems
5. Office
6. Institutions
7. Lab
8. Water Purification
9. Ice Makers
10. Beverage Dispensing
11. Vending
12. R.V.
