    Product Details:

    Place of Origin: CHINA
    Brand Name: BRANDO
    Certification: CE
    Model Number: DMF

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: negotiation
    Packaging Details: Inner Box,Carton,Pallet
    Delivery Time: 4-7 days
    Payment Terms: T/T, Western Union, L/C, MoneyGram
    Supply Ability: 165000 pieces per month
    Contact Now
    Detailed Product Description
    Product Name: BFEC Pulse Valve Valve Type: Right Angle Type, Quick Mount Type, Embedded Type, Flanged Type, Straight Through Type
    Port Size: 3/4'', 1'', 1-1/2'', 2'', 2-1/2'', 3'', 3-1/2'', 4'' Valve Operation: Diaphragm Pilot Operated
    Voltage: 24VDC, 110VAC, 220VAC DMF-Z Series: DMF-Z-20, DMF-Z-25, DMF-Z-40S, DMF-Z-50S, DMF-Z-62S, DMF-Z-76S, DMF-Z-102S
    DMF-Y Series: DMF-Y-25, DMF-Y-40S, DMF-Y-50S, DMF-Y-62S, DMF-Y-76S, DMF-YA-76S, DMF-YB-76S, DMF- Y-102S, DMF-Y-102SA, DMF-Y-102SE DMF-ZM Series: DMF-ZM-20, DMF-ZM-25, DMF-ZM-40S, DMF-ZL-B
    DMF-T Series: DMF-T-20, DMF-T-25S, DMF-T-40S, DMF-T-50S, DMF-T-62S DMF-ZF Series: DMF-ZF-25, DMF-ZF-40S
    High Light:

    BFEC Pulse Valve

    ,

    BFEC Diaphragm Valve

    ,

    BFEC Solenoid Valve

    BFEC Pulse Valve



    DMF Series BFEC Pulse Jet Valve:



    1. Right Angle Pulse Jet Valve: DMF-Z-20, DMF-Z-25, DMF-Z-40S, DMF-Z-50S, DMF-Z-62S, DMF-Z-76S, DMF-Z-102S


    2. Quick Mount Pulse Jet Valve: DMF-ZM-20, DMF-ZM-25, DMF-ZM-40S, DMF-ZL-B


    3. Immersion (Embedded) Pulse Jet Valve: DMF-Y-25, DMF-Y-40S, DMF-Y-50S, DMF-Y-62S, DMF-Y-76S, DMF-YA-76S, DMF-YB-76S, DMF-

    Y-102S, DMF-Y-102SA, DMF-Y-102SE


    4. Flanged Pulse Jet Valve: DMF-ZF-25, DMF-ZF-40S


    5. Straight Through Pulse Jet Valve: DMF-T-20, DMF-T-25S, DMF-T-40S, DMF-T-50S, DMF-T-62S



    Technical Data of DMF-Z series Right Angle Pulse Jet Valves:

    Model
    Nominal diametrer
    Number of diaphragms
    Inlet
    Outlet
    mm
    inch
    DMF-Z-20
    Φ20
    3/4''
    1
    G3/4''
    G3/4''
    DMF-Z-25
    Φ25
    1'''
    1
    G1''
    G1''
    DMF-Z-40S
    Φ40
    1 1/2''
    2
    G1 1/2''
    G1 1/2''
    DMF-Z-50S
    Φ50
    2''
    2
    G 2''
    G2
    DMF-Z-62S
    Φ62
    2 1/2''
    2
    G2 1/2''
    G2 1/2''
    DMF-Z-76S
    Φ76
    3''
    2
    G3''
    G3''
    DMF-Z-90S
    Φ90
    3 1/2''
    2
    G3 1/2''
    G3 1/2''
    DMF-Z-102S
    Φ102
    4''
    2
    G4''
    G4''
    DMF-20L-B
    Φ20
    3/4''
    1
    G3/4''
    Φ27



    Technical Data of DMF-ZM series Quick Mount Pulse Jet Valves:

    Model
    DMF-ZM-20
    DMF-ZM-25
    DMF-ZM-40S
    Nominal Size
    20
    25
    40
    Port size
    mm
    20
    25
    40
    in
    3/4
    1
    1 1/2
    Blowing Area (m2)
    3.5~6
    8~10
    12~16
    Number of Diaphragms
    1
    1
    2
    Flow
    Kv
    17.55
    26.16
    45.82
    Cv
    20.48
    50.53
    53.47
    Pressure (Psi)
    0.1Mpa~0.8Mpa
    Temperature (℃)
    -25℃ to +80℃
    Voltage
    220VAC, 110VAC, 24VDC



    Technical Data of  DMF-Y series Submerged Pulse Jet Valves:

    Model number
    DMF-Y-25
    DMF-Y-40S
    DMF-Y-50S
    DMF-Y-62S
    DMF-Y-76S
    DMF-Y-102S
    Port sizes
    G1''
    G1 1/2''
    G2''
    G2 1/2''
    G3''
    G4''
    Membrane sizes
    (φ66 smaller)
    φ96
    φ112
    φ160
    φ188
    φ202
    φ255
    CV values
    30.53
    53.47
    71.47
    150.85
    186.66
    313.09
    Blowing area
    (m2)
    8-10
    12-16
    18-28
    27-38
    37-65
    70-90
    Environment Temperature
    -25℃ to +80℃
    Relative Humidity
    ≤85%
    Working Medium
    Clean Air
    Protection Class
    IP65
    Service Life
    Over one million times
    Voltage
    24VDC, 110VAC, 220VAC



    More BFEC Pulse Valve For You to Choose:

    BFEC Pulse Valve 0BFEC Pulse Valve 1BFEC Pulse Valve 2

               Right Angle Type                         Quick Mount Type                         Submerged Type

    BFEC Pulse Valve 3BFEC Pulse Valve 4 BFEC Pulse Valve 5 BFEC Pulse Valve 6

                Diaphragm                     Solenoid Coil                  Armature Assembly            Pulse Controller



    Focus on your demands, Offer you best solution:



    √ Contact us if some points you have doubt

    √ Contact us if somewhere need to change
    √ Contact us if not the one you are looking for

    √ Contact us if you are doing designing



    Welcome to your any question and inquiry!
