Vessel G 1 / 4 " Inlets Air Compressor Parts Pressure Switch With M20x1.5 Mounting Connection

Large Image : Vessel G 1 / 4 " Inlets Air Compressor Parts Pressure Switch With M20x1.5 Mounting Connection

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO or OEM
Certification:	CE ISO
Model Number:	P series

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	negotiation
Packaging Details:	inner box, carton, then packed by pallet
Delivery Time:	7
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Part Name:	Pressure Control Switch	Application:	To Protect Compressor
Ambient Temperature:	-40 To150℃	Color:	White, Also Can Be Customized
Max Voltage:	AC110V AC220V	Reset:	AUTO
Highlight:	Air Compressor On Off Switch , Compressed Air Pressure Switch

Vessel G 1 / 4 " Inlets Air Compressor Parts Pressure Switch With M20x1.5 Mounting Connection

Introduction:
1, P series pressure control can protect compressors in refrigeration and air-condition plant, and keep them from over-low pressure or over-high suction pressure.
2, P series pressure controls can start and stop refrigeration compressors and fans of air condensers.
3, P series pressure controls can be used not only in fluoride refrigeration, but also in air and liquid.
4, P series pressure controls are fitted with 3 kinds of changeover switch: a single pole double throw (SPDT), a double pole single throw(DPST) and a double pole double throw(DPDT). The position of the switch is determined by the pressure control setting and the pressure at the connector.

Technical Data:

Ambient temperature	-20 ~ 50°C
Medium temperature	-25 ~ 120°C
Cable connection	The cable entry can be used for 15mm dia.

Max. working pressure
L.P	1 MPa
H.P	3 Mpa

Max. test pressure
L.P	1.65 MPa
H.P	3.3 MPa

R410a Technical Data:

Ambient Temperature	-40 ~ 65℃
Medium Temperature	-40 ~ 120℃
Diameter of connection wire hole	15mm
Max. working pressure	L.P.: 1.2MPa H.P.: 4.5MPa
Max. testing pressure	L.P.: 2.5MPa H.P.: 4.8MPa

Electrical data:
Vessel G 1 / 4 " Inlets Air Compressor Parts Pressure Switch With M20x1.5 Mounting Connection 0

Connection type:

Type and Data (Unit: MPa)

Symbol	Model	Low pressure		High pressure		Reset		Max. work presure
		Adjust range	Differential	Adjust range	Differential	L.P.	H.P.	L.P.	H.P.
Low Pressure L.P.	P2	0-0.2	0.04-0.1			AUTO		1.7
Low Pressure L.P.	P3	-0.05-0.3	0.1-0.2			AUTO		1.7
Low Pressure L.P.	P6M	-0.05-0.6	≤0.2 Fixed			Manual		1.7
Low Pressure L.P.	P6	-0.05-0.6	0.1-0.4			AUTO		1.7
Low Pressure L.P.	P10	0.1-1.0	0.1-0.3			AUTO		1.7
Low Pressure L.P.	P12L	0.2-1.2	0.1-0.5			AUTO		2.5
High Pressure H.P.	P12D			0.2-1.2	0.1-0.4		AUTO		3.3
High Pressure H.P.	P16D			0.3-1.7	0.2-0.5		AUTO		3.3
High Pressure H.P.	P20D			0.4-2.0	0.2-0.5		AUTO		3.3
High Pressure H.P.	P30D			0.5-3.0	0.5-1.0		AUTO		3.3
High Pressure H.P.	P30			1.0-3.0	≤0.4 Fixed		AUTO		3.3
High Pressure H.P.	P30M			0.5-3.0	≤0.4 Fixed		Manual		3.3
High Pressure H.P.	P45L			1.0-4.5	≤0.4 Fixed		AUTO		4.8
High Pressure H.P.	P45DL			1.0-4.5	0.5-1.5		AUTO		4.8
Dual Pressure	P830	-0.05-0.6	0.1-0.4	0.5-3.0	≤0.4 Fixed	AUTO	AUTO	1.7	3.3
	P830HM	-0.05-0.6	0.1-0.4	0.5-3.0	≤0.4 Fixed	AUTO	AUTO	1.7	3.3
	P830HLM	-0.05-0.6	≤0.4 Fixed	0.5-3.0	≤0.4 Fixed	Manual	Manual	1.7	3.3
	P1245L	0.2-1.2	0.1-0.5	1.0-4.5	≤0.6 Fixed	AUTO	AUTO	2.5	4.8
	P1245LHM	0.2-1.2	0.1-0.5	1.0-4.5	≤0.6 Fixed	AUTO	Manual	2.5	4.8
	P1245LHLM	0.2-1.2	≤0.2 Fixed	1.0-4.5	≤0.6 Fixed	Manual	Manual	2.5	4.8

Mounting Plate (Unit: mm):
Vessel G 1 / 4 " Inlets Air Compressor Parts Pressure Switch With M20x1.5 Mounting Connection 2

Dimensions(unit: mm):

Single pressure:

Symbol	A	B	C
Low pressure	34.4	36	22.4
High pressure	22	32.7	18.5

Vessel G 1 / 4 " Inlets Air Compressor Parts Pressure Switch With M20x1.5 Mounting Connection 5
Dual pressure:
