Jorc Type Auto Drain Valve

Jorc Type Auto Drain Valve

Jorc Type Auto Drain Valve
Jorc Type Auto Drain Valve

Product Details:

Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BADV01

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Product Name: Air Compressor Auto Drain Valve Port Size: 1/8'', 1/4'', 3/8'', 1/2''
Voltages: 24VDC, 110VAC, 220VAC Solenoid Coil: Class H, IP65
Valve Types: OPTIMUM, COMBO Valve Body Material: Brass, Stainless Steel (For High Pressure)
Seal Material: VITON (FKM) Timer Cycle Range (ON / OFF): 0.5 To 10seconds / 0.5 To 45 Minutes
Timer Cycle Indicatin: Bright LED Illumination Application: Air Compressors, Air Receivers, Air Filters And Refrigerated Air Dryers.
High Light:

Jorc Timer Drain Valve

,

Jorc Auto Drain Valve

,

Jorc Electronic Drain Valve

Jorc Type Auto Drain Valve



Brando is a air compressor auto drain valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. The air compressor auto drain valve is suitable for a wide range of compressed air applications including compressors, receivers, filters and refrigerated air dryers.



The COMBO auto drain valve combines an adjustable electronic timer controlled drain, a ball valve and a mesh strainer into one compact easy to install package.



The OPTIMUM auto drain valve with an easily adjustable electronic timer, a direct acting solenoid valve, a large orifice and options for a brass or stainless steel body, this drain provides reliable compact condensate removal.



Main Dimension of Air Compressor Auto Drain Valve:

Jorc Type Auto Drain Valve 0  Jorc Type Auto Drain Valve 1

Model
BADV01
BADV02
Port Size
1/8'', 1/4'', 3/8'', 1/2''
Valve Type
OPTIMUM
COMBO
Operation Type
2/2 Way, Direct Acting
Power Connection
DIN 43650 Form A
Voltages
24VDC, 110VAC, 220VAC (50/60Hz)
Body Material
Brass, Stainless Steel (For High Pressure)
Seal Material
FKM
Insulation Class
H
Protection Class
IP65
Timer Cycle Range (ON / OFF)
0.5 - 10seconds / 0.5 - 45 minutes
Timer Cycle Indicatin
Bright LED illumination
Test Feature
Yes
Pressure Range
0 - 230 PSI
Medium Temperature
34 - 131℉



Application Examples from customer feed back:

Jorc Type Auto Drain Valve 2



Air Compressor Auto Drain Valve Spare Parts:

auto drain valve timerauto drain valve parts solenoid coilauto drain valve parts

              Solenoid Valve Timer                              Solenoid Valve Coil                           Solenoid Valve Armature



Brando Solenoid Valve Factory Production Video:



More Air Compressor Solenoid Valve for you to choose:

Jorc Type Auto Drain Valve 6Jorc Type Auto Drain Valve 7

Jorc Type Auto Drain Valve 8Jorc Type Auto Drain Valve 9



FAQ:



1. How does air compressor auto drain work?
Some compressed air auto drains work on the float principal. As water and contamination accumulates in the bottom of the bowl, it will ultimately lift a float. The compressed air, under pressure in the bowl, will then vent to atmosphere through the drain opening, blowing the water and debris from the bowl as it does.



2. How often should I drain my air compressor tank?
There is no need to drain your tank at every single use, however, we recommend that your tank be drained once every couple of days if it's used daily. If you drain it once a week, you should be doing everything that is needed to prevent major rust.
