Place of Origin: | China, Ningbo |
Brand Name: | BRANDO |
Certification: | CE, ISO |
Model Number: | OPTIMUM |
Minimum Order Quantity: | 1 pc |
---|---|
Price: | Negotiation |
Packaging Details: | Box, Carton, Pallet |
Delivery Time: | 4 to 7 Working Days |
Payment Terms: | L/C, T/T, Western Union, Paypal |
Supply Ability: | 100000 pcs per month |
Product Name: | Auto Drain Valve | Port Size: | 1/2'' |
---|---|---|---|
Orifice Size: | 4.5mm | Working Pressure: | 0 To 230 PSI |
Seal Material: | VITON | Valve Body Material: | Brass |
Coil Voltages: | 24VDC, 110VAC, 220VAC | Application: | Air Compressor, Air Receiver, Air Filter, Air Dryer, Etc |
Highlight: | Jorc Auto Drain Valve,Timer Auto Drain Valve,Auto Drain Solenoid Valve |
Jorc Type Timer Auto Drain Solenoid Valve For Air Compressor 220V
The OPTIMUM timer controlled condensate drain is suitable for a wide range of compressed air applications including compressors, receivers, filters and refrigerated air dryers.
With an easily adjustable electronic timer, a direct acting solenoid valve, a large orifice and options for a brass or stainless steel body, this drain provides reliable compact condensate removal.
The OPTIMUM is easy to install, simple to adjust and rated for pressures up to 230 PSI. It includes a test switch, LED on/off indication and a serviceable valve. Most importantly, the large 4.5 mm orifice means it is perfect for difficult applications with high condensate flow rates and solid particulate contaminants.
Technical data of Air Compressor Auto Drain Valve:
BRANDO Model
|
BADV01
|
BADV02
|
Port Size
|
1/8'', 1/4'', 3/8'', 1/2''
|
|
Valve Type
|
OPTIMUM
|
COMBO
|
Operation Type
|
2/2 Way, Direct Acting
|
|
Power Connection
|
DIN 43650 Form A
|
|
Voltages
|
24VDC, 110VAC, 220VAC
|
|
Body Material
|
Brass, Stainless Steel (For High Pressure)
|
|
Seal Material
|
FKM
|
|
Protection Class
|
IP65
|
|
Timer Cycle Range (ON / OFF)
|
0.5 to 10 seconds / 0.5 to 45 minutes
|
|
Timer Cycle Indication
|
Bright LED illumination
|
|
Test Feature
|
Yes
|
|
Pressure Range
|
0 - 230 PSI
|
|
Medium Temperature
|
34 - 131 ℉
|
Dimension of Air Compressor Automatic Drain Valve:
![]() |
![]() |
OPTIMUM | COMBO |
Product Video of OPTIMUM Auto Drain Valve:
Application of Timer Auto Drain Valve:
BRANDO factory production video of solenoid valve:
More Auto Drain Valves and Spare Parts for you to choose:
![]() |
![]() |
![]() |
![]() |
Auto Drain Valves | Solenoid Valve Timer | Solenoid Valve Coil | Solenoid Valve Armature |
More Air Compressor Solenoid Valves for you to choose:
![]() |
![]() |
![]() |
![]() |
6014 | 6014 FLNSCH | 0400 | 5404 |
![]() |
![]() |
![]() |
![]() |
VXD23 | VXD23-B | VXD22 | 0927 & 0955 Series |
