Name: Normally Open Solenoid Valve 322H75 G1/2'' 40 bar DC24V AC220V
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 322H75
Price: 51.00 USD
Availability: InStock

Home Products Brass Solenoid Valve

Normally Open Solenoid Valve 322H75 G1/2'' 40 bar DC24V AC220V

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	322H75

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	1/2''	Orifice Size:	15mm
Action:	Diaphragm Pilot Operated	Media:	Water, Air, Gas
Body Material:	Brass	Pressure Range:	0.3 To 40 Bar
Voltage:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC	Function:	2 Way Normally Open
Application Examples:	Bottle Blowing Machine, Laser Cutting Machine, Air Compressor, Etc
Highlight:	1/2 inch high pressure solenoid valve , 322H75 normally open solenoid valve , Parker 322H75

Normally Open Solenoid Valve 322H75 G1/2'' 40 bar DC24V AC220V

322H75 is a Parker Lucifer H Series 2/2-way normally open (N.O.) pilot-operated solenoid valve. It is designed for high-pressure on/off control of dry or lubricated air, neutral gases, liquids and oil, depending on the seal and application configuration. Parker documentation identifies the 322H75 with a 1/2-inch connection, 15 mm orifice, 40 bar maximum differential pressure and NBR sealing.

Typical Applications

Parker identifies the 322H Series for high-pressure shut-off applications such as:

Air compressors
Compressed-air systems
Car-washing equipment
Machine-tool cooling
Industrial process equipment
Neutral-gas control
Oil and liquid control systems

The series is specifically described for ON/OFF control of dry or lubricated air, neutral gases and compatible liquids/oil.

Technical Data:

Model No	Port Size	Orifice Size	Working Pressure (bar)	Body	Seal	Voltage
Model No	Port Size	Orifice Size	Working Pressure (bar)	Body	Seal	Voltage
Normally Closed
321H35	G1/2''	15mm	1.5 to 40	Brass	PUR	24VDC 24VAC 110VAC 220VAC
321H36	G3/4''	20mm	1.5 to 40		PUR
321F35	Sub-Base	14mm	1.5 to 40		PUR
421F36	Sub-Base	14mm	0 to 13		PUR
Normally Open
322H35	G1/2''	15mm	1.5 to 40	Brass	PUR	24VDC 24VAC 110VAC 220VAC
322H36	G3/4''	20mm	1.5 to 40		PUR
322F35	Sub-Base	14mm	1.5 to 40		PUR
322H75	G1/2''	15mm	0.3 to 40		NBR FKM
