2V130-15 Airtac Type Brass Solenoid Valve 1/2'' 12VDC 24VDC 110VAC 220VAC

2V130-15 Airtac Type Brass Solenoid Valve 1/2'' 12VDC 24VDC 110VAC 220VAC

  • 2V130-15 Airtac Type Brass Solenoid Valve 1/2'' 12VDC 24VDC 110VAC 220VAC
2V130-15 Airtac Type Brass Solenoid Valve 1/2'' 12VDC 24VDC 110VAC 220VAC
Product Details:
Place of Origin: China, Ningbo
Brand Name: BRANDO
Certification: CE, ISO
Model Number: 2V130-15
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Box, Carton, Pallet
Delivery Time: 4 to 7 days
Payment Terms: T/T, PayPal, Western Union
Supply Ability: 20000 pcs per month
Contact Now
Detailed Product Description
Port Size: 1/2'' Orifice Size: 13mm
Function: 2 Way, Normally Closed Operation: Diaphragm Piloted Operated
Body Material: Brass Diaphragm Material: NBR, EPDM, VITON
Working Medium: Water, Oil, Air, Etc Working Pressure Range: 0.05 To 1MPa (7 To 145psi)
Proof Pressure: 1.5MPa (215psi) Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
High Light:

Airtac Solenoid Valve 2V130-15

,

1/2'' Brass Solenoid Valve

,

Airtac 2V130-15

2V130-15 Airtac Type Brass Solenoid Valve 1/2'' 12VDC 24VDC 110VAC 220VAC



2V130 and 250 Series
1.This 2/2 way diaphragm piloted solenoid valve has low energy consumption and large air flow.
2.The starting pressure is low and the operational differential pressure is < 0.05MPa.
3.The valve body is made of brass which is heat resistant and the coil conforms to Class B classification. The seals are made of NBR.



Main Dimension of 2V Series Brass Solenoid Valve:

2V130-15 Airtac Type Brass Solenoid Valve 1/2'' 12VDC 24VDC 110VAC 220VAC 0

Model
A
AB
AC
B
C
CA
D
P
PA
2V130-10
72
18.5
71
49
91
103
32
3/8''
15
2V130-15
72
18.5
71
49
91
103
32
1/2''
15
2V250-20
102
23
74
77.5
107.5
120
45
3/4''
21
2V250-25
102
23
74
77.5
107.5
120
45
1''
21


Technical Data of 2V Series Brass Solenoid Valve:

Model
2V025-06
2V025-08
2V130-10
2V130-15
2V250-20
2V250-25
Fluid
Air, Water, Oil
Acting
Direct Acting
Internally Piloted Acting
Initial State
Normally Closed
Orifice Size (mm)
2.5
13
25
Cv
0.23
0.25
6.2
6.2
13
13
Port Size
1/8''
1/4''
3/8''
1/2''
3/4''
1''
Viscosity limit
Under 20CST
Pressure Range
0 to 1MPa (0 to 145psi)
0.05 to 1MPa (7 to 145psi)
Proof Pressure
1.5 MPa (215psi)
Body Material
Brass with zinc plated
Brass
Seal
Material
NBR, EPDM, VITON
NBR, EPDM, VITON
Activating
Time
0.05 sec and below


BRANDO Factory Production of Brass Solenoid Valves:
