OLAB Type 7000 Steam Iron Solenoid Valve 220-230V/50Hz 1/4 Inch

OLAB Type 7000 Steam Iron Solenoid Valve 220-230V/50Hz 1/4 Inch

This is 7000 solenoid valve, 1/4'' female threaded port, 2mm or 3mm orifice size, flow rate control by adjusting needle, 0 to 10 bar working pressure, 2 way normally closed, brass body, FKM seal, various voltages for your choice, 12VDC, 24VDC, 24VAC, 110VAC or 220VAC, etc. It is popularly used in steam iron or steam boiler to control steam flow rate.

Technical Data:

Main Dimension:

Our Production:

FAQ:

Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of applications.

Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.

Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.
