CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V

CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V

  • CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V
  • CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V
  • CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V
  • CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V
CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V
Product Details:
Place of Origin: CHINA
Brand Name: BRANDO
Certification: None
Model Number: 5541
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: Negotiation
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Welding Machine Solenoid Valve Inlet Size: 1/8''
Outlet Size: Hose Connection (6.5mm OD) Orifice Size: 2mm
Seal Material: NBR, EPDM, FKM Working Pressure Range: 0 To 8 Bar
Body Material: Brass Working Temperature Range: NBR: -5 To +120 ºC, EPDM: -30 ℃ To +120℃, FKM: -30 ℃ To +150℃
Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC Working Medium: Gas
Highlight:

CEME Solenoid valves for industry 5541

,

TIG Welding Machine Brass Solenoid Valve

,

MIG Welding Machine Solenoid Valve 220v

CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V


Product Features:

1. Model No: 5541
2. Port Size: Inlet: 1/8'', Outlet: Hose Connection (6.5mm OD)
3. Orifice Size: 2mm
4. Body Material: Brass
5. Seal Material: NBR, EPDM, FKM
6. Working Medium: Gas
7. Working Medium Temperature Range: NBR: -5 to +120 ºC, EPDM: -30 ℃ to +120℃, FKM: -30 ℃ to +150℃
8. Working Pressure Range: 0 to 8 bar
9. Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
10. Application: MIG, TIG Welding Machine


Dimension and Data of 5541 Solenoid Valve:

CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 0

Port Size
1/8'', 1/4''
Orifice Size
1mm to 3mm
Body Material
Brass
Seal Material
NBR, EPDM, FKM
Working Medium
Water, Air, Gas, Oil, Steam, etc
Working Medium Temperature Range
NBR: -10 ℃ to +80 ℃
EPDM: -30 ℃ to +120 ℃
FKM: -30 ℃ to +150 ℃
Working Pressure Range
0 to 10 bar
Operation
Direct Acting
Function
2 Way Normally Closed
Voltage
DC: 12V, 24V
AC: 24V, 110V, 120V, 220V, 230V (50/60Hz)


BRANDO Solenoid Valve Production Video:


More Coffee Machine Solenoid Valves for you to choose:


Brass Solenoid Valve
CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 1 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 2 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 3 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 4
CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 5 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 6 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 7 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 8


Plastic Solenoid Valve
CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 9 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 10 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 11 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 12
CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 13 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 14 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 15 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 16


Manifold Solenoid Valve
CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 17 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 18 CEME Type Solenoid Valves 5541 For MIG TIG Welding Machine AC220V AC110V 19


Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
