CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V

CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V

  • CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V
  • CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V
  • CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V
  • CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V
CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V
Product Details:
Place of Origin: CHINA
Brand Name: BRANDO
Certification: None
Model Number: 5510
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: Negotiation
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Port Size: 1/8'', 1/4'' (G, NPT) Orifice Size: 1mm To 3mm
Seal Material: NBR, EPDM, FKM Working Pressure Range: 0 To 10 Bar
Body Material: Brass Action: Direct Acting
Function: 2 Way Normally Closed Working Temperature Range: NBR: -5 To +120 ºC, EPDM: -30 ℃ To +120℃, FKM: -30 ℃ To +150℃
Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Highlight:

Solenoid valve CEME 5510 NC 1/8''

,

CEME Solenoid Valve 1/8''

,

CEME Solenoid valves for industry 5510

CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V


Product Features:

1. Port Size: 1/8'', 1/4'' (G, NPT)
2. Orifice Size: 1mm to 3mm
3. Body Material: Brass
4. Seal Material: NBR, EPDM, FKM
5. Working Medium: Water, Air, Gas, Oil, Steam, etc
6. Working Medium Temperature Range: NBR: -5 to +120 ºC, EPDM: -30 ℃ to +120℃, FKM: -30 ℃ to +150℃
7. Working Pressure Range: 0 to 10 bar
8. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC


Dimension and Data of Solenoid Valve:

CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 0

Port Size
1/8'', 1/4''
Orifice Size
1mm to 3mm
Body Material
Brass
Seal Material
NBR, EPDM, FKM
Working Medium
Water, Air, Gas, Oil, Steam, etc
Working Medium Temperature Range
NBR: -10 ℃ to +80 ℃
EPDM: -30 ℃ to +120 ℃
FKM: -30 ℃ to +150 ℃
Working Pressure Range
0 to 10 bar
Operation
Direct Acting
Function
2 Way Normally Closed
Voltage
DC: 12V, 24V
AC: 24V, 110V, 120V, 220V, 230V (50/60Hz)


BRANDO Solenoid Valve Production Video:


More Coffee Machine Solenoid Valves for you to choose:


Brass Solenoid Valve
CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 1 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 2 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 3 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 4
CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 5 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 6 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 7 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 8


Plastic Solenoid Valve
CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 9 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 10 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 11 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 12
CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 13 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 14 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 15 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 16


Manifold Solenoid Valve
CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 17 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 18 CEME Type Brass Solenoid Valve for Industry 5510 NC 1/8'' 24V 220V 19


Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!

Tag:

Brass Electric Solenoid Valve,

Brass Body Solenoid Valve,

Brass Solenoid Valve Water
