Name: 1/4 Inch 2W025-08 Brass Electric Solenoid Valve 24V 100V 220V
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 2W025-08S
Price: 51.00 USD
Availability: InStock

Home Products Brass Solenoid Valve

1/4 Inch 2W025-08 Brass Electric Solenoid Valve 24V 100V 220V

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	2W025-08S

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	1/4''	Orifice Size:	2.5mm
Action:	Direct Acting	Media:	Water Air Gas
Body Material:	Brass	Diaphragm Material:	NBR, FKM, EPDM
Voltage:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC	Coil Type:	IP65
Highlight:	2 way solenoid valve 1/4'' , 2W025-08 Electric Solenoid Water Valve , 2W025-08 Brass Electric Valve

1/4 Inch 2W025-08 Brass Electric Solenoid Valve 24V 100V 220V

2W025-08 Normal Closed (N/C) Electric Solenoid Valve Is Constructed With Brass Body;standard seal material defaults to Nitrile rubber,suitable for a variety of working media.
Used to control the direction, flow, speed of medium in industry.
This 220V AC brass electric solenoid valve easily replaces broken valves for use with water, air, and gas (viscosity≤20cst).
This unit fits a 1/4" NPT thread.

1.This 220V AC brass solenoid valve Wide range of uses In industry

2..Rated voltage: AC110V / AC220V / DC24V (50 / 60Hz).Voltage Tolerance: 10%

3.The Operation Fluid Viscosity of Solenoid Valve is 20 CST below.

4.Valve body is made of brass and sealing material is NBR, with good medium compatibility, high reliability, long service life and low cost.

Specifications of 2W, UD & UW Series 2/2 Way Brass Solenoid Valves:

Ref No	Model No	Pipe Size	CV	Orifice	Fluid Temp. (°C)	Operating Pressure kgf/ cm2 (bar)
Ref No	Model No	Pipe Size	CV	Orifice	Fluid Temp. (°C)	Water	Air	Light oil
UD-6	2W025-06	1/8''	0.23	2.5mm	-5°C- +80°C	0~7	0~7	0~7
UD-8	2W025-08	1/4''	0.23	2.5mm	-5°C- +80°C	0~7	0~7	0~7
UD-10	2W040-10	3/8''	0.58	4mm	-5°C- +80°C	0~10	0~10	0~10
UW-10	2W160-10	3/8"	4.5	15mm	-5°C- +80°C	0~5	0~7	0~5
UW-15	2W160-15	1/2''	4.5	15mm	-5°C - +80°C	0~5	0~7	0~5
UW-20	2W200-20	3/4"	8.6	20mm	-5°C- +80°C	0~5	0~7	0~5
UW-25	2W250-25	1"	12	25mm	-5°C- +80°C	0~5	0~7	0~5
UW-35	2W350-35	1-1/4"	24	35mm	-5°C- +80°C	0~5	0~7	0~5
UW-40	2W400-40	1-1/2"	28	40mm	-5°C - +80°C	0~5	0~7	0~5
UW-50	2W500-50	2"	48	50mm	-5°C - +80°C	0~5	0~7	0~5

Main dimension of 2W & 2S Series Solenoid Valves:
1/4 Inch 2W025-08 Brass Electric Solenoid Valve 24V 100V 220V 0

2S Series	2W Series	A	B	C	D	E
2S025-06	2W025-06	64.5	30	75	43	1/8''
2S025-08	2W025-08	64.5	30	75	43	1/4''
2S040-10	2W040-10	70.6	32	82.4	53	3/8''
2S160-10	2W160-10	101.5	57	117	69	3/8''
2S160-15	2W160-15	101.5	57	117	69	1/2''
2S200-20	2W200-20	107	57	123.5	73	3/4''
2S250-25	2W250-25	111.5	73.5	134.5	99	1''
2S350-35	2W350-35	142	95	172	123	1-1/4''
2S400-40	2W400-40	142	95	172	123	1-1/2''
2S500-50	2W500-50	172	123	209	168	2''

Details of Solenoid Water Valve:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!

Tag:

Contact Person: Mr. Brandon Bao

Tel: 86-13454729544

Fax: 86-574-83879820
