Name: 2W050-15 1/2'' AIRTAC Type Brass Solenoid Valve 2 Way 24V 110V 220V
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 2W050-15
Price: 51.00 USD
Availability: InStock

Home Products Brass Solenoid Valve

2W050-15 1/2'' AIRTAC Type Brass Solenoid Valve 2 Way 24V 110V 220V

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	None
Model Number:	2W050-15

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiation
Packaging Details:	Box, Carton, Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Product Name:	Solenoid Valve	Port Size:	1/2''
Orifice Size:	5mm	Body Material:	Brass
Seal Material:	NBR (Standard), EPDM, FKM (Optional)	Working Medium:	Water, Air, Gas, Liquid, Etc
Function:	2 Way Normally Closed	Action:	Direct Acting
Working Pressure:	0 To 10 Bar	Voltage:	220VAC, 110VAC, 24VAC, 24VDC, 12VDC
Highlight:	Airtac Solenoid Valve 2W050-15 , Brass Water Solenoid Valve , Solenoid Valve Brass 1/2''

2W050-15 Airtac Type Brass Solenoid Valve

Product Features:

1. Working Medium: Water, Air, Gas, Liquid, etc

2. Max Working Pressure: 10 bar

3. Medium Temperature: NBR (-5 to +80ºC), EPDM (-5 to +120ºC), FKM (-10 to +150ºC)

4. Port Size: 1/8'', 1/4'', 3/8'', 1/2'', 3/4'', 1''

5. Orifice Size: 3mm, 5mm, 15mm, 20mm, 25mm

6. Body Material: Brass

7. Seal Material: NBR (Standard), EPDM, FKM

8. Operation: Direct Acting (DN3 to DN5), Pilot Operated (DN15 to DN25)

9. Function: 2 Way Normally Closed

10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data:

Model No	2W030-06	2W030-08	2W050-10	2W050-15	2W150-10	2W150-15	2W200-20	2W250-25
Port Size	1/8''	1/4''	3/8''	1/2''	3/8''	1/2''	3/4''	1''
Orifice Size	3mm	3mm	5mm	5mm	15mm	15mm	20mm	25mm
CV	0.33	0.33	0.83	0.83	5.5	5.5	9.5	12.5
Body Material	Brass
Seal Material	NBR (Standard), EPDM, FKM
Working Medium	Water, Air, Gas, Liquid, etc
Working Temperature	NBR: -5 to +80℃ EPDM: -5 to +120℃ FKM: -10 to +150℃
Working Pressure	0 to 10 bar				0.5 to 10 bar
Operation	Direct Acting				Pilot Operated
Function	2 Way Normally Closed
Supply Voltage	12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Main Dimension:

Model No	Port	A	B	C	D	L
2W030-06	1/8''	60	25	70	41	16
2W030-08	1/4''	60	25	70	41	16
2W050-10	3/8''	72	31	85	52	23
2W050-15	1/2''	72	31	85	52	23
2W150-10	3/8''	92	46	105	70	/
2W150-15	1/2''	92	46	105	70	/
2W200-20	3/4''	96	53	113	82	/
2W250-25	1''	102	59	122	92	/
