Name: DN40 PN16 Flange Port Pneumatic Angle Seat Valve Single or Double Acting
Brand: Ningbo Brando Hardware Co., Ltd
SKU: ASV40SSF40
Price: 49.10 USD
Availability: InStock

Home Products Pneumatic Cylinder Valve

DN40 PN16 Flange Port Pneumatic Angle Seat Valve Single or Double Acting

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	None
Model Number:	ASV40SSF40

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiation
Packaging Details:	Box, Carton, Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	50000pcs per month

Contact Now

Detailed Product Description

Product Name:	Pneumatic Angle Seat Valve	Port Connection:	Flange
Port Size:	DN40	Body Material:	Stainless Steel 304
Seal Material:	PTFE	Actuator Material:	Stainless Steel
Function:	Single Acting Normally Closed, Double Acting Normally Closed, Double Acting Normally Open	Working Medium:	Water, Air, Steam, Gas, Liquid, Etc
Medium Working Pressure:	0 To 16 Bar	Medium Working Temperature:	-10℃ To +180℃
Highlight:	Pneumatic Flange Angle Seat Valve , Pneumatic Angle Seat Valve DN40 , Pneumatic Steam Angle Seat Valve

DN40 PN16 Flange Port Pneumatic Angle Seat Valve

A pneumatic angle seat valve is a type of valve that uses compressed air to actuate the movement of a plug or disc, which in turn controls the flow of fluids or gases. The angled design of the seat allows for higher flow rates and is commonly used in applications requiring fast response times and accurate flow control, such as in sterilizers, filling systems, and process control.

Technical Data:

Product Name	Pneumatic Angle Seat Valve
Port Size	1/2'' to 4''
Orifice Size	DN10 to DN100
Port Connection	Threaded, Flanged, Welded, Tri Clamp
Body Material	Stainless Steel 304, Stainless Steel 316
Seal Material	PTFE
Actuator Material	Plastic, Stainless Steel
Function	Single Acting Normally Closed Double Acting Normally Closed Double Acting Normally Open
Working Medium	Water, Air, Steam, Gas, Liquid, etc
Medium Temperature	-10 to +180℃
Ambient Temperature	-10 to +60℃
Working Pressure	0 to 1.6 MPa

Main Dimension:

DN Size	L	D	D1	D2	H	A	B	N-Φd	Actuator
DN15	131	90	65	42.5	157	180	61.5	4-Φ14	50
DN20	136	100	75	53.5	161	188	61.5	4-Φ14	50
DN25	140	110	85	63	173	198	61.5	4-Φ14	50
DN32	150	130	100	74	198	220	75.5	4-Φ18	63
DN40	180	140	110	82.5	205	236	75.5	4-Φ18	63
DN50	195	154	125	96	208	245	75.5	4-Φ18	63
DN65	230	185	145	115	315	320	126	4-Φ18	80
DN80	250	195	160	130	330	330	126	8-Φ18	100
DN100	280	215	180	150	350	360	156	8-Φ18	100

DN Size	L	D	D1	D2	H	A	B	N-Φd	Actuator
DN15	131	90	65	43	155	185	66.5	4-Φ14	50
DN20	131	100	75	53.8	160	185	66.5	4-Φ14	50
DN25	141	110	85	63.5	197	220	82.5	4-Φ14	63
DN32	150	130	100	74	195	225	82.5	4-Φ18	63
DN40	178	140	110	83.5	203	240	82.5	4-Φ18	63
DN50	195	154	125	97	229	275	103	4-Φ18	80
DN65	230	185	145	115	315	320	126	4-Φ18	100
DN80	250	195	160	130	330	330	126	8-Φ18	100
DN100	280	215	180	150	350	360	156	8-Φ18	125

Our Production:

DN40 PN16 Flange Port Pneumatic Angle Seat Valve Single or Double Acting 2

Related Products:


Pneumatic Limit Switch	Pneumatic Valve	Pneumatic FRL	Positioner

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
