L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel

L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel

  • L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel
L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q644
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball Power: Pneumatic
Pipe Connection: Flanged Body Material: Cast Steel, SS304, SS316
Seal Material: PTFE, TFM Working Medium: Neutral Gas, Air
Orifice Size: DN15 To DN200 Way Number: 3 Way
Flow Direction: L Pattern, T Pattern Medium Temperature: PTFE: -20 To +180℃, TFM: -30 To +230℃
Highlight:

Pneumatic Flanged Ball Valve

,

3 Way Pneumatic Ball Valve

,

Three Way Ball Valve Pneumatic

L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel



Our air actuated ball valve is a high quality control valve, which is used in many types of process control applications. These valves are used in the oil, gas, automotive, chemical, treatment, power processing, pharmaceutical, cosmetic, beverage, and food industries, just to name a few. These valves can be used manually, or if automation is required, they can come equipped with an ISO direct mounting pad cast on the top of the valve. The variations of design and material ensure that the correct performance standard can be met for any application.



Our air actuated ball valve is a superior design to other types of valves due to its high performance standards. Some of the different design types include industrial, sanitary, three piece, flanged, double union, two piece, multi-port, grooved end, and high pressure. These ball valves are well suited to the many different ways that ball valves are utilized in today’s process control applications.



Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Flow Direction of 3 Way Pneumatic Ball Valve:

L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 0



Main Dimension of Pneumatic Ball Valve:

L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 1

L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 2



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 3 L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 4 L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 5 L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 6
L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 7 L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 8 L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 9 L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 10
Pneumatic Butterfly Valves
L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 11 L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 12 L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 13 L T Pattern 3 Way Pneumatic Flanged Ball Valve Stainless Steel 14
