Y Type Pneumatic Flanged Angle Seat Valve Stainless Steel

Y Type Pneumatic Flanged Angle Seat Valve Stainless Steel

  • Y Type Pneumatic Flanged Angle Seat Valve Stainless Steel
Y Type Pneumatic Flanged Angle Seat Valve Stainless Steel
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: JZF-F
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Port Size: 1/2'' To 4'' Orifice Size: DN15 To DN100
Port Connections: Flanged Working Fluids: Netral And Aggressive Liquid, Gas
Body Material: Stainless Steel (304, 316) Seal Material: PTFE
Working Pressure Range: 0.4 To 0.8 MPa Max. Working Pressure Range: 1.6 MPa
Highlight:

Pneumatic Flanged Angle Seat Valve

,

Pneumatic Flange Angle Seat Valve

,

Industrial Flange Angle Seat Valve

Y Type Pneumatic Flanged Angle Seat Valve Stainless Steel



The angle-seat valves from BRANDO offer a long service life, reliable on-off and precise control performance. Due to the angled arrangement of the valve actuators in relation to the pipeline, the compact angle seat on-off and control valves can be installed and operated even in very confined spaces.



Compared to traditional globe valves, the angle seat design from BRANDO offers a higher flow capacity. This design is also easy to insulate, which significantly reduces heat losses at the angle seat valve itself. The body provides various combination with different actuator types for a wide range of applications in industrial piping systems.



Technical Data of Pneumatic Angle Seat Valve:

Medium Temperature
-10 to +180℃
Ambient Temperature
-10 to +60℃
Max. Working Pressure Range
1.6 MPa
Working Medium
Netral and Aggressive Liquid, Gas
Working Pressure
0.4 to 0.8 MPa
Body Material
SS304, SS316
Seal Material
PTFE
Connection Size
1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2'', 2-1/2'', 3'', 4''
Port Connections
Threaded, Flanged, Welded, Clamp
Nominal Diameter
DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100
Safety setting in case of power failure
Normally Closed, Normally Open





Main Dimension of Pneumatic Angle Seat Valve:



Stainless Steel Body With Plastic Actuator

                                  Y Type Pneumatic Flanged Angle Seat Valve Stainless Steel 0

Y Type Pneumatic Flanged Angle Seat Valve Stainless Steel 1





Stainless Steel Body With Stainless Steel Actuator

                                          DN40 1 1/2'' Flanged Air Actuated Angle Seat Piston Valve Pneumatic 0

DN40 1 1/2'' Flanged Air Actuated Angle Seat Piston Valve Pneumatic 1





Brando Factory Valve Production:





More Pneumatic Angle Seat Valves for you to choose:

Stainless Steel Pneumatic Threaded Angle Seat Valve Double Acting 2 Stainless Steel Pneumatic Threaded Angle Seat Valve Double Acting 3
Stainless Steel Pneumatic Threaded Angle Seat Valve Double Acting 4 Stainless Steel Pneumatic Threaded Angle Seat Valve Double Acting 5
