| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 6027 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 100000 pcs per month |
| Port Size: | 1/4'', 3/8'', 1/2'' | Orifice Size: | 3mm, 4mm, 5mm, 6mm, 8mm, 10mm |
|---|---|---|---|
| Operation: | Plunger Direct Acting | Function: | 2 Way, Normally Closed |
| Body Material: | Brass | Seal Material: | NBR, EPDM, FKM |
| Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | ||
| Highlight: | 1/4'' Plunger Solenoid Valve,6027 Plunger Solenoid Valve,Type 6027 Solenoid Valve |
||
1/4'' 2/2 Way Brass Plunger Solenoid Valve 6027 A Direct Acting
6027 is a direct-acting plunger solenoid valve. Various seal material combinations are available depending on the application. The coils are moulded with chemically resistant epoxy. In combination with a DIN43650A plug, the valves satisfy protection class IP65.
Technical Data of 6027 Solenoid Valve:
| Model |
Port Size (inch) |
Orifice Size (mm) |
Kv Value (m³/h) |
Pressure Range (bar) |
Body Material | Seal Material | Voltage | Dimension | ||
| A | F | K | ||||||||
| 2 Way Normally Closed, Direct Acting | ||||||||||
| 6027 | 1/4'' | 3 | 0.28 | 0 to 30 |
Brass Stainless Steel |
NBR: -10 to +80℃ |
12VDC 24VDC 24VAC 110VAC 220VAC |
50 | 32 | 83/78 |
| 4 | 0.54 | 0 to 25 | 50 | 32 | 83/78 | |||||
| 5 | 0.73 | 0 to 10 | 50 | 32 | 83/78 | |||||
| 6 | 0.95 | 0 to 6 | 50 | 32 | 83/78 | |||||
| 3/8'' | 3 | 0.28 | 0 to 30 | 50 | 32 | 83/78 | ||||
| 4 | 0.54 | 0 to 25 | 50 | 32 | 83/78 | |||||
| 5 |
0.73 |
0 to 10 | 50 | 32 | 83/78 | |||||
| 6 | 0.95 | 0 to 6 | 50 | 32 | 83/78 | |||||
| 8 | 1.6 | 0 to 3.5 | 50 | 32 | 83/78 | |||||
| 1/2'' | 3 | 0.23 | 0 to 25 | 50/55 | 32 | 83 | ||||
| 4 | 0.3 | 0 to 8 | 50/55 | 32 | 83 | |||||
| 5 | 0.35 | 0 to 6 | 50/55 | 32 | 83 | |||||
| 6 | 0.95 | 0 to 6 | 50/55 | 32 | 83 | |||||
| 8 | 1.6 | 0 to 3.5 | 50/55 | 32 | 83 | |||||
| 10 | 1.8 | 0 to 2 | 50/55 | 32 | 83 | |||||
