AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron

AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron

  • AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron
  • AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron
AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: D671
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Product Name: Pneumatic Butterfly Valve Orifice Size: DN40 To DN300
Connection Type: Wafer Body Material: Cast Iron
Seal Material: PTFE Working Medium: Neutral Gas, Air
Highlight:

DN80 Wafer Butterfly Valve

,

Cast Iron Wafer Butterfly Valve

,

Pneumatic Actuated Butterfly Valve

AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron



BRANO’s range of pneumatically controlled butterfly valves, which are used to control the flow of a media remotely. They can have either a lug or wafer connection style. Based on the actuator design (single or double acting) the actuator will open and close the butterfly valve with compressed air (single acting uses a spring to either open or close the valve). The butterfly valve has a disc that rotates with the actuator to open or close the butterfly valve. The butterfly valve design allows for good sealing properties, durability, and reliability for your application. Pneumatic actuators are a reliable solution and often used to control larger valves than electric actuators at a lower investment cost. There are various housings, seals, and sizes of pneumatically controlled butterfly valves to allow you to find the right one for your application.



Technical Data of Pneumatic Butterfly Valve:

Pneumatic Butterfly Valve
Electric Butterfly Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Main Dimension of Pneumatic Butterfly Valve:

AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 0

AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 1



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 2 AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 3 AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 4 AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 5
AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 6 AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 7 AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 8 AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 9
Pneumatic Butterfly Valves
AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 10 AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 11 AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 12 AT075D Pneumatic Actuated Wafer Butterfly Valve DN80 Cast Iron 13



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
