| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE, ISO |
| Model Number: | 321H35, 321H36 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Working Medium: | Water, Air, Gas | Port Size: | 1/2'', 3/4'' |
|---|---|---|---|
| Orifice Size: | 15mm | Operation Mode: | 2 Way, Normally Closed |
| Operation: | Diaphragm Pilot Operated | Body Material: | Brass |
| Pressure Range: | 1.5 To 50 Bar | Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz) |
| High Light: | 1/2'' Brass Solenoid Valve,15mm Brass Solenoid Valve,Parker 321H35 |
||
1/2'' 15mm 321H36 Brass Solenoid Valve For Bottle Blowing Machine
Product Features of High Pressure Solenoid Valve:
1. Operating pressure up to 5 MPa, Media temperature range from -5℃ to 80℃, Port size is 1/2'', 3/4''.
2. Pilot operated, fast response.
3. Suitable for media of water, gas, acetylene, liquefied gas etc, with kinematic viscosity ≤ 1 mm²/s.
4. Coil are encapsulated with thermoset plastics.
5. Usually applied to the bottle blowing machines.
Technical Data of High Pressure Solenoid Valve:
Main Dimension of High Pressure Solenoid Valve:
Brando Solenoid Valve Factory Production Video:
More High Pressure Solenoid Valves for you to choose:
| Brass Solenoid Valves | |||
|
|
|
|
| MAX 50 bar | MAX 50 bar | MAX 50 bar | MAX 50 bar |
|
|
|
|
| MAX 50 bar | MAX 70 bar | MAX 120 bar | MAX 200 bar |
| Stainless Steel Solenoid Valves | |||
|
|
|
|
| MAX 50 bar | MAX 50 bar | MAX 50 bar | MAX 100 bar |
|
|
|
|
| MAX 120 bar | MAX 160 bar | MAX 200 bar | MAX 300 bar |
