PGJ Plug-In Reducer Straight Pneumatic Hose Fittings Automatic

PGJ Plug-In Reducer Straight Pneumatic Hose Fittings Automatic

Pneumatic Hose Fittings provide the essential link between tubes, hoses and other components in a pneumatic system. Air fittings feature tighter seals and have lower pressure requirements than hydraulic fittings and are typically offered in various connector types. In addition to connecting pneumatic components and stopping the flow of unused ports, miniature fittings are also used to control air flow pressure and directional flow.

BRANDO's Pneumatic Hose Fittings Features:

1. Optional shapes of release sleeve: As a manufacturer, BRANDO can provide Oval and Round Release Sleeve.

2. Multiple colors of release sleeve: Blue, Black, Orange, Red, Gray

3. Accommodate kinds of connection thread type: R (PT, BSPT), G (BSPP), NPT, UNF, UNC, Metric.

4. Accommodate metric size tubing OD: 3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 16mm.

5. Accommodate inch size tubing OD: 1/8", 5/32", 3/16", 1/4", 5/16", 3/8", 1/2", 5/8".

Technical data of Pneumatic Hose Fittings:

Specifications of PGJ Plug-In Straight Pneumatic Hose Fittings:

List of All Push To Connect Pneumatic Hose Fittings:

Choosing the Right Fittings for Your Pneumatic System:

Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.

Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
