SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80

SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80

  • SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80
SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: SK-80
Payment & Shipping Terms:
Minimum Order Quantity: 4pcs
Price: Negotiation
Packaging Details: Box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 10000pcs per month
Contact Now
Detailed Product Description
Product Name: Pneumatic Air Knocker Inlet Size: 3/8''
Exhaust Size: 3/8'' Body Material: Aluminum Alloy
Operating Pressure: 0.3 To 0.7 MPa Air Consumption: 0.455 L/Time
Impact Force: 19.3 To 29.5 Kgm/s Net Weight: 7.6kg
Highlight:

Air Knocker SK-80

,

Pneumatic Air Knocker

,

Pneumatic Percussion Hammer

SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80



This is SK-80 air knocker similar to SEISHIN. Pneumatic air knocker keeps on hammering without a break to remove powder clogging and adhesion in hoppers and pipes, which are popularly used for many applications in fields such as manufacturing, food processing and pharmaceuticals.



Technical Data:

Model No

Working Pressure

(bar)

Air Consumption

(L/Time)

Wallop

(kgm/sec)
SK-30 3 to 7 0.028 ~0.75
SK-40 3 to 7 0.082 ~2.2
SK-60 3 to 7 0.228 ~7.4
SK-80 4 to 5 0.455 ~16.4
SK-100 5 to 7 1.012 ~30.0



Main Dimension:

SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80 0

Model No A B C D E G H L S T Y R
SK-30 75 10 82 13 9 1/8'' 132 68 6 50 27 1/4''
SK-40 90 12 97 18 11 1/4'' 162 78 10 60 34 1/4''
SK-60 121 13 143 19 15 1/4'' 215 100 10 60 48 1/4''
SK-80 160 17 170 20 17 3/8'' 260 140 14 90 70 3/8''
SK-100 200. 18 200 23 17 3/8'' 318 160 18 90 70 3/8''


Installation Examples:

SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80 1



Our Production:

SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80 2



Related Products:

SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80 3 SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80 4
Pneumatic Fitting Pneumatic Silencer



Similar Products:

SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80 5 SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80 6 SK-80 SEISHIN Type Pneumatic Percussion Hammer Air Knocker SK80 7
Pneumatic Ball Vibrator Pneumatic Turbine Vibrator Pneumatic Roller Vibrator



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
