Name: SK-30 SEISHIN Type Pneumatic Air Knocker For Hopper Silo SK30
Brand: Ningbo Brando Hardware Co., Ltd
SKU: SK-30
Price: 49.10 USD
Availability: InStock

Home Products Pneumatic Hose Fittings

SK-30 SEISHIN Type Pneumatic Air Knocker For Hopper Silo SK30

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	SK-30

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiation
Packaging Details:	Box, Carton, Pallet
Delivery Time:	4 to 7 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	10000pcs per month

Contact Now

Detailed Product Description

Product Name:	Pneumatic Air Knocker	Inlet Size:	1/4''
Exhaust Size:	1/8''	Body Material:	Aluminum Alloy
Operating Pressure:	0.3 To 0.7 MPa	Air Consumption:	0.028 L/Time
Impact Force:	1 To 1.5 Kgm/s	Net Weight:	1.1kg
Highlight:	Air Knocker SK-30 , Pneumatic Air Knocker , Air Knocker For Hopper

SK-30 SEISHIN Type Pneumatic Air Knocker For Hopper Silo SK30

This is SK-30 air knocker similar to SEISHIN. Pneumatic air knocker keeps on hammering without a break to remove powder clogging and adhesion in hoppers and pipes, which are popularly used for many applications in fields such as manufacturing, food processing and pharmaceuticals.

Technical Data:

Model No	Working Pressure (bar)	Air Consumption (L/Time)	Wallop (kgm/sec)
SK-30	3 to 7	0.028	~0.75
SK-40	3 to 7	0.082	~2.2
SK-60	3 to 7	0.228	~7.4
SK-80	4 to 5	0.455	~16.4
SK-100	5 to 7	1.012	~30.0

Main Dimension:

SK-30 SEISHIN Type Pneumatic Air Knocker For Hopper Silo SK30 0

Model No	A	B	C	D	E	G	H	L	S	T	Y	R
SK-30	75	10	82	13	9	1/8''	132	68	6	50	27	1/4''
SK-40	90	12	97	18	11	1/4''	162	78	10	60	34	1/4''
SK-60	121	13	143	19	15	1/4''	215	100	10	60	48	1/4''
SK-80	160	17	170	20	17	3/8''	260	140	14	90	70	3/8''
SK-100	200.	18	200	23	17	3/8''	318	160	18	90	70	3/8''

Installation Examples:

SK-30 SEISHIN Type Pneumatic Air Knocker For Hopper Silo SK30 1

Our Production:

SK-30 SEISHIN Type Pneumatic Air Knocker For Hopper Silo SK30 2
