1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine

1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine

  • 1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine
  • 1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine
  • 1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine
1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 550C-02
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Medium: Water, Air, Oil, Hot Water, Steam, Etc Port Size: 1/8''
Orifice Size: 2.0mm, 2.8mm Seal Material: NBR, FKM, EPDM
Body Material: Brass Working Pressure Range: 0 To 6 Bar
Function: 2 Way Normally Closed Coil Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
High Light:

1/8'' Brass Solenoid Valve

,

2/2 Way NC Brass Solenoid Valve

,

5503 Solenoid Valve

1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine



Product Feature of Brass Solenoid Valve:

1. Port Size: 1/8''
2. Orifice Size: 2.0mm, 2.8mm
3. Body Material: Brass
4. Seal Material; NBR, FKM, EPDM
5. Working Medium; Water, Air, Oil, Steam, etc
6. Working Medium Temperature Range: NBR: -20 to +80 ℃, EPDM: -10 to +120℃, FKM: -30 ℃ to +150℃
7. Working Pressure Range: 0 to 6 Bar
8. Voltages: DC: 12V, 24V; AC: 24V, 110V, 120V, 220V, 230V (50/60Hz)



Dimension and Data of Brass Solenoid Valve:

1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine 0

Working Medium
Water, Air, Oil, Hot Water, Steam, etc
Working Temperature
FKM: -30 to +150℃
Working Pressure
0 to 6 Bar
Port Size
1/8''
Orifice Size
2.0mm, 2.8mm
Function
2 Way Normally Closed
Operation
Direct Acting
Voltage
DC: 12VDC, 24VDC
AC: 24VAC, 110VAC, 120VAC, 220VAC, 230VAC (50/60Hz)
Tolerance
±10%
Material
Body: Brass or Stainless Steel
Seal: FKM
Armature Tube: Stainless Steel 304
Plunger: Stainless Steel 430F
Stop: Stainless Steel 430F
Spring: Stainless Steel 304
Shading Ring: Stainless Steel 304


Brando Factory Production of Solenoid Valves:



More Steam Iron Solenoid Valves for you to choose:

1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine 1 1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine 2 1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine 3 1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine 4
1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine 5 1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine 6 1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine 7 1/8'' 2/2 Way NC Brass Solenoid Valve 5503 For Coffee Machine 8



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
