DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel

DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel

  • DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel
DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: JZF-DN40-SS-F
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Port Size: 1 1/2'' Port Connections: Flanged
Orifice Size: 40mm Working Fluids: Netral And Aggressive Liquid, Gas
Body Material: SS304, SS316 Seal Material: PTFE
Working Pressure Range: 0.4 To 0.8 MPa Max. Working Pressure Range: 1.6 MPa
Highlight:

DN40 Angle Seat Valve

,

1-1/2'' Flanged Angle Seat Valve

,

Angle Seat Valve Actuator

DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel



The angle-seat valves from BRANDO offer a long service life, reliable on-off and precise control performance. Due to the angled arrangement of the valve actuators in relation to the pipeline, the compact angle seat on-off and control valves can be installed and operated even in very confined spaces.



Compared to traditional globe valves, the angle seat design from BRANDO offers a higher flow capacity. This design is also easy to insulate, which significantly reduces heat losses at the angle seat valve itself. The body provides various combination with different actuator types for a wide range of applications in industrial piping systems.



Main Dimension of Angle Seat Valve:



Stainless Steel Body With Stainless Steel Actuator

                                  DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel 0

DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel 1



Technical Data of Angle Seat Valve:

Medium Temperature
-10 to +180℃
Ambient Temperature
-10 to +60℃
Max. Working Pressure Range
1.6 MPa
Working Medium
Netral and Aggressive Liquid, Gas
Working Pressure
0.4 to 0.8 MPa
Body Material
SS304, SS316
Seal Material
PTFE
Connection Size
1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2'', 2-1/2'', 3'', 4''
Port Connections
Threaded, Flanged, Welded, Clamp
Nominal Diameter
DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100
Safety setting in case of power failure
Normally Closed, Normally Open



Angle Seat Valve Disassembly Display:

DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel 2



Brando Factory Valve Production:



More Angle Seat Valves for you to choose:

DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel 3 DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel 4 DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel 5
DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel 6 DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel 7 DN40 1-1/2'' Flanged Air Actuated Angle Seat Valve Stainless Steel 8
