Name: Direct Acting Diaphragm Brass Water Solenoid Valve 2W400-40 1.5''
Brand: Brando
SKU: 2W400-40
Rating: 4.5 (144 reviews)

Home Products Brass Solenoid Valve

Direct Acting Diaphragm Brass Water Solenoid Valve 2W400-40 1.5''

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2W400-40

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Valve Series:	2W Series	Ref. Number:	UNI-D Type UW-40
Voltage:	AC110V AV220V DC24V	Action:	Pilot Diaphragm Drive
Port Size:	1-1/2' Inch	Media:	Water Air Gas
Fluid Viscossity:	Below 20 CST	Power:	Solenoid
Body Material:	Brass	Diaphragm Material:	NBR, FKM And EPDM
High Light:	2W400-40 Water Solenoid Valve , 1.5'' Water Solenoid Valve , UNI-D UW-40

Direct Acting Diaphragm Brass Water Solenoid Valve 2W400-40 1.5''

The 2W400-40 solenoid valve is brass valves two-way, semi-direct lift valve that operates in a normally closed position.This means that there are two ports in which the medium flows and the valve will open to allow the medium to pass when the coil is energized. 2 / 2 Way G1-1/2 Inch Normal Close Type Operated Brass Solenoid Valve 2W400-40.High quality electric solenoid valve, for water, air or oil. It's applicable in many fields.

2W400-40

2W: 2 Positon 2 Way Solenoid Valve. Solenoid valve has 2 pipe connections, an inlet called the cavity port and an outlet called the body orifice port. When the valve is energized the plunger opens allowing media to flow through the valve in the cavity port and out the body orifice port.Turn off the power. The orifice closes and flow through the valve stops.

400: The Aperture of Flow Rate is 40 mm

40:Joint Pipe Bore is G1-1/2 Inch Female Thread

Technical Data of 2W & 2S Solenoid Valve:

2W Series	2W025-08	2W040-10	2W160-15	2W200-20	2W250-25	2W350-35	2W400-40	2W500-50
2S Series	2S025-08	2S040-10	2S160-15	2S200-20	2S250-25	2S350-35	2S400-40	2S500-50
Orifice Size	2.5	4	15	20	25	35	40	50
Port Size	1/4''	3/8''	1/2''	3/4''	1''	1-1/4''	1-1/2''	2''
Medium	Water, Air, Gas, Oil
Action	Direct Acting		Semi-Direct Diaphragm Operated
Function	2 Way, Normally Closed
Fluid Viscosity	20 CST below
Pressure Range	0 to 1.0 Mpa
Temp. Range	-5 to +85℃

Main dimension of 2W & 2S Series Solenoid Valves:
Direct Acting Diaphragm Brass Water Solenoid Valve 2W400-40 1.5'' 0

2S Series	2W Series	A	B	C	D	E
2S025-06	2W025-06	64.5	30	75	43	1/8''
2S025-08	2W025-08	64.5	30	75	43	1/4''
2S040-10	2W040-10	70.6	32	82.4	53	3/8''
2S160-10	2W160-10	101.5	57	117	69	3/8''
2S160-15	2W160-15	101.5	57	117	69	1/2''
2S200-20	2W200-20	107	57	123.5	73	3/4''
2S250-25	2W250-25	111.5	73.5	134.5	99	1''
2S350-35	2W350-35	142	95	172	123	1-1/4''
2S400-40	2W400-40	142	95	172	123	1-1/2''
2S500-50	2W500-50	172	123	209	168	2''

Main Part OF 2W Solenoid Valve and its Material:

Main Body: Brass

Coil: Special Copper Wire

Core: Stainless Steel

Tube: Stainless Steel

Spring: Stainless Steel

Plug: NBR, Viton, Silicon

Diaphragm: NBR, Viton, Silicon
