Name: DC24V AC220V UD-10 2W040-10 3/8 Inch Electromagnetic Valve
Brand: Brando
SKU: 2W040-10
Rating: 4.9 (121 reviews)

Home Products Brass Solenoid Valve

DC24V AC220V UD-10 2W040-10 3/8 Inch Electromagnetic Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2W040-10

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Voltages:	24V DC, 110V AC, 120V AC, 220V AC, 230V AC, 240V AC	Power:	Solenoid
Media:	Water, Gas, Oil	Port Size:	3/8''
Function:	2/2 Way Noramlly Closed	Operation Type:	Direct Acting, Semi-Direct Operated
Valve Body Material:	Brass	Diaphragm:	NBR, FKM And EPDM
UD Series Model No:	UD-6, UD-8, UD-10	UW Series Model No:	UW-10, UW-15, UW-20, UW-25, UW-35, UW-40, UW-50
High Light:	UD-10 Electromagnetic Valve , 2W040-10 Electromagnetic Valve , UNI-D UD-10

DC24V AC220V UD-10 2W040-10 3/8 Inch Electromagnetic Valve

2W040-10

2W: 2 Positon 2 Way Solenoid Valve. Solenoid valve has 2 pipe connections, an inlet called the cavity port and an outlet called the body orifice port. When the valve is energized the plunger opens allowing media to flow through the valve in the cavity port and out the body orifice port.Turn off the power. The orifice closes and flow through the valve stops.

40: The Aperture of Flow Rate is 4 mm

10:Joint Pipe Bore is G3/8 Inch Female Thread

Dimension of 2W/2S Water Solenoid Valve :

Dimension od 2W/2S Water Solenoid Valve

2S Series	2W Series	A	B	C	D	E
2S025-06	2W025-06	64.5	30	75	43	G1/8''
2S025-08	2W025-08	64.5	30	75	43	G1/4''
2S040-10	2W040-10	70.6	32	82.4	53	G3/8''
2S160-10	2W160-10	101.5	57	117	69	G3/8''
2S160-15	2W160-15	101.5	57	117	69	G1/2''
2S200-20	2W200-20	107	57	123.5	73	G3/4''
2S250-25	2W250-25	111.5	73.5	134.5	99	G1''
2S350-35	2W350-35	142	95	172	123	G1-1/4''
2S400-40	2W400-40	142	95	172	123	G1-1/2''
2S500-50	2W500-50	172	123	209	168	G2''

Technical Data:

2W Series	2W025-08	2W040-10	2W160-15	2W200-20	2W250-25	2S350-35	2S400-40	2S500-50
2S Series	2S025-08	2S040-10	2S160-15	2S200-20	2S250-25	2S350-35	2S400-40	2S500-50
Orifice Size	2.5	4	15	20	25	35	40	50
Port Size	1/4''	3/8''	1/2''	3/4''	1''	1-1/4''	1-1/2''	2''
Medium	Water, Air, Oil, Gas, Steam
Action	Direct Acting		Semi-Direct
Function	2 Way, Normally Closed
Fluid Viscosity	20 CST below
Pressure Range	0 to 1.0 Mpa
Temp. Range	-5 to +100℃

Product Features:
1. UW series is direct, multiplex, connected diaphragm, conductive and normally closed (NC) 2/2 way solenoid valve;

2. Able to be operated directly under low pressure;

3. Availability of fluid type:water, air, light oil;

4. Diaphragm accept for customization NBR, Viton, Silicone and EPDM.
