Place of Origin: | China |
Brand Name: | Brando |
Certification: | CE |
Model Number: | JZF-DN32-SS |
Minimum Order Quantity: | 1 pc |
---|---|
Price: | Negotiation |
Packaging Details: | Inner boxes, Carton, Pallet |
Delivery Time: | 4-8 days |
Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
Supply Ability: | 100000 pcs per month |
Port Size: | 1/2'' To 4'' | Port Connections: | Threaded |
---|---|---|---|
Orifice Size: | DN15 To DN100 | Working Fluids: | Netral And Aggressive Liquid, Gas |
Body Material: | SS304, SS316 | Seal Material: | PTFE |
Working Pressure Range: | 0.4 To 0.8 MPa | Max. Working Pressure Range: | 1.6 MPa |
Highlight: | Pneumatic Threaded Angle Seat Valve,Internal Thread Pneumatic Angle Seat Valve,Industrial Thread Pneumatic Angle Seat Valve |
Pneumatic Threaded Angle Seat Valve With Stainless Steel Actuator
Pneumatic angle seat valve is a general switch in the automatic control system which are suitable in demanding applications such as steam, water and aggressive media. They are especially suited for vacuum and fast acting applications that require a long service life. It is widely used in printing, dyeing, bleaching, food, washing, chemical, water treatment, pharmacy and other automatic machinery and equipment. It is featured with water hammer protection, noise-free, reliable sealing performance.
Main Dimension of Angle Seat Valve:
Stainless Steel Body With Stainless Steel Actuator
Technical Data of Angle Seat Valve:
Brando Factory Valve Production:
More Angle Seat Valves for you to choose:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
