Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50

Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50

  • Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50
Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: D671
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Product Name: Pneumatic Butterfly Valve Orifice Size: DN40 To DN300
Connection Type: Wafer Body Material: Stainless Steel 304
Seal Material: Rubber Working Medium: Neutral Gas, Air
High Light:

Stainless Steel Pneumatic Actuator Butterfly Valve

,

Soft Seat Wafer Pneumatic Butterfly Valve

,

Stainless Steel Pneumatic Butterfly Valve 2''

Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50



Air Actuated Butterfly Valve is composed of pneumatic actuator and butterfly valve. The basic working principle of pneumatic valve is that compressed air enters the pneumatic actuator to drive the piston, and then rotating or liting torsion shaft drives the stem. Pneumatic Butterfly Valve is a circular disc rotating with the stem as an opening and closing function, in order to achieve the opening action of the pneumatic valve, mainly for the use of cut-off Valve, can also be designed to have the function of regulation or section valve and regulation At present, the use of butterfly valve in low pressure large and medium diameter pipeline is more and more.



Technical Data of Pneumatic Butterfly Valve:

Pneumatic Butterfly Valve
Electric Butterfly Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Main Dimension of Pneumatic Butterfly Valve:

Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 0

Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 1



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 2 Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 3 Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 4 Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 5
Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 6 Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 7 Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 8 Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 9
Pneumatic Butterfly Valves
Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 10 Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 11 Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 12 Soft Seat Wafer Pneumatic Actuator Butterfly Valve Stainless Steel 2'' DN50 13



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
