Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel

Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel

  • Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel
Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q641
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball Power: Pneumatic
Pipe Connection: Flanged Body Material: Stainless Steel (304, 316)
Seal Material: PTFE, TFM Working Medium: Neutral Gas, Air
Orifice Size: DN15 To DN200
High Light:

Pneumatic Flange Ball Valve

,

Stainless Steel Pneumatic Ball Valve

,

Pneumatic Flanged Ball Valve

Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel



Pneumatic ball valves are used to control the flow of a media, liquid or gas, by means of a rotating ball with a bore. The rotating ball is controlled by a pneumatic actuator that is capable of turning it. A ball valve is one of the most common valves due to their simple operation, reliability, long service life, and wide range of application uses.



2-way pneumatic ball valves have 2 ports, an inlet and an outlet. The media flows from one direction to the other and the valve is used to open or close the flow. A 2-way ball valve is commonly called a shut off valve.



3-way pneumatic ball valves have 3 ports. The bore in the ball is not straight, but rather in an L or T formation. This allows for various circuit functions (flow directions) for the valve. It can be used to distribute, mix, or divert flow in the desired direction. Therefore, any of the 3 ports can be an inlet or an outlet.



Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Main Dimension of Pneumatic Ball Valve:

Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 0

Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 1



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 2 Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 3 Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 4 Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 5
Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 6 Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 7 Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 8 Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 9
Pneumatic Butterfly Valves
Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 10 Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 11 Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 12 Two Piece Pneumatic Actuator Flange Ball Valve 1'' DN25 Stainless Steel 13



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
