3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch

3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch

  • 3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch
3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q614
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball Power: Pneumatic
Pipe Connection: Female Thread Body Material: Cast Steel, SS304, SS316
Seal Material: PTFE, TFM Working Medium: Neutral Gas, Air
Port Size: 1/2'' To 2'' Way Number: 3 Way
Flow Direction: L Pattern, T Pattern Medium Temperature: PTFE: -20 To +180℃, TFM: -30 To +230℃
High Light:

3 Way Ball Valve Pneumatic Actuator

,

Pneumatic Actuator 3 Way Ball Valve

,

3-Way Ball Valve With Pneumatic Actuator

3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch



BRANDO supply single acting spring return air actuated ball valve and double acting air reuturn pneumatic air actuated ball valve use pressurized air to open and close the ball valve. The characteristic of the air actuated ball valve is that it has a higher flow rate, temperature and pressure. It is ideal for the hazardous environments and high temperature such as hot water and steam applications. Our air actuated ball valve is a high quality control valve, which is used in many types of process control applications. These valves are used in the oil, gas, automotive, chemical, treatment, power processing, pharmaceutical, cosmetic, beverage, and food industries, just to name a few. These valves can be used manually, or if automation is required, they can come equipped with an ISO direct mounting pad cast on the top of the valve. The variations of design and material ensure that the correct performance standard can be met for any application.



Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
280VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Flow Direction of 3 Way Pneumatic Ball Valve:

3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 0



Main Dimension of Pneumatic Ball Valve:

3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 1

3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 2



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 3 3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 4 3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 5 3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 6
3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 7 3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 8 3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 9 3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 10
Pneumatic Butterfly Valves
3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 11 3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 12 3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 13 3 Way Stainless Steel Ball Valve With Pneumatic Actuator Limit Switch 14



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
