2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator

2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator

  • 2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator
2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q611
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball Power: Pneumatic
Pipe Connection: Female Thread Body Material: Stainless Steel (304, 316)
Seal Material: PTFE, TFM Working Medium: Neutral Gas, Air
Port Size: 1/2'' To 4''
High Light:

3 Piece Ball Valve With Pneumatic Actuator

,

Pneumatic Ball Valve 2''

,

Pneumatic Ball Valve DN50

2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator



Pneumatic ball valve types:

Pneumatic brass ball valves have brass as their housing material. They are very common, durable, and can be used with water, compressed air, oils, non-aggressive media, and much more. They commonly have water or gas approvals.



Pneumatic PVC ball valves have PVC as their housing material. They are typically used for water management and irrigation applications as they are suitable for corrosive media (sea water), most acids and bases, salt solutions, organic solvents, and much more.



Pneumatic stainless steel ball valves have stainless steel as their housing material. They are typically used for aggressive and corrosive media. Stainless steel is also highly wear, temperature, and pressure resistant.



Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Main Dimension of Pneumatic Ball Valve:

2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 0

2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 1



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 2 2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 3 2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 4 2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 5
2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 6 2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 7 2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 8 2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 9
Pneumatic Butterfly Valves
2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 10 2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 11 2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 12 2'' DN50 Stainless Steel 3 Piece Ball Valve With Pneumatic Actuator 13



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
