SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC

SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC

  • SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC
SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 55AE-08
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Medium: Water, Air, Oil, Hot Water, Steam, Etc Connection: Threaded
Orifice Size: 1.0mm, 1.5mm, 2.0mm, 2.6mm Seal Material: FKM
Body Material: Brass Working Pressure Range: 0 To 20 Bar
Function: 2 Way Normally Closed Coil Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
High Light:

SAGE Coffee Maker Solenoid Valve

,

Solenoid Valve For SAGE Coffee Maker

,

Coffee Maker Solenoid Valve 220V

SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC



Product Feature:

1. Working Medium: Water, Air, Oil, Hot Water, Steam, etc
2. Working Temperature: -30 to +150℃
3. Working Pressure: 0 to 20 Bar
4. Connection: Threaded
5. Orifice Size: 1.0mm, 1.5mm, 2.0mm, 2.6mm

6. Function: 2 Way Normally Closed
7. Operation: Direct Acting
8. Voltage: DC: 12VDC, 24VDC; AC: 24VAC, 110VAC, 120VAC, 220VAC, 230VAC (50/60Hz)



Dimension and Data of Coffee Machine Solenoid Valve:

SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 0

Working Medium
Water, Air, Oil, Hot Water, Steam, etc
Working Temperature
FKM: -30 to +150℃
Working Pressure
0 to 20 Bar
Body Port size
1/8''
Port Thread
G, NPT
Orifice Size
1.0mm, 1.5mm, 2.0mm, 2.6mm
Function
2 Way Normally Closed
Operation
Direct Acting
Voltage
DC: 12VDC, 24VDC
AC: 24VAC, 110VAC, 120VAC, 220VAC, 230VAC (50/60Hz)
Tolerance
±10%
Material
Body: Brass, Stainless Steel
Seal: FKM
Amature Tube: Stainless Steel 304
Plunger: Stainless Steel 430F
Stop: Stainless Steel 430F
Spring: Stainless Steel 304
Shading ring: Stainless Steel 304



Brando Factory Production of Solenoid Valves:



More Coffee Machine Solenoid Valves for you to choose:



Brass Solenoid Valve
SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 1 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 2 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 3 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 4
SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 5 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 6 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 7 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 8



Plastic Solenoid Valve
SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 9 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 10 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 11 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 12
SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 13 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 14 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 15 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 16



Manifold Solenoid Valve
SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 17 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 18 SAGE Espresso Coffee Maker Solenoid Valve 2 Way 220V 230V AC 19
