| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 5541 |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Welding Machine Solenoid Valve | Inlet Size: | 1/8'' |
|---|---|---|---|
| Outlet Size: | Hose Connection (6.5mm OD) | Orifice Size: | 2mm |
| Body Material: | Brass | Seal Material: | NBR, EPDM, FKM |
| Working Medium: | Gas | Working Medium Temperature Range: | NBR: -5 To +120 ºC, EPDM: -30 ℃ To +120℃, FKM: -30 ℃ To +150℃ |
| Working Pressure Range: | 0 To 8 Bar | Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| High Light: | CEME Solenoid Valve 5541,TIG Welding Machine Solenoid Valve,MIG Welding Machine Solenoid Valve |
||
5541 CEME Type Brass Gas Solenoid Valve For MIG TIG Welding Machine 24V 220V
Product Features:
1. Model No: 5541
2. Port Size: Inlet: 1/8'', Outlet: Hose Connection (6.5mm OD)
3. Orifice Size: 2mm
4. Body Material: Brass
5. Seal Material: NBR, EPDM, FKM
6. Working Medium: Gas
7. Working Medium Temperature Range: NBR: -5 to +120 ºC, EPDM: -30 ℃ to +120℃, FKM: -30 ℃ to +150℃
8. Working Pressure Range: 0 to 8 bar
9. Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
10. Application: MIG, TIG Welding Machine
Dimension and Data of 5541 Solenoid Valve:
BRANDO Solenoid Valve Production Video:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Echo
Tel: +8613454729544
