| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 5503 |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Solenoid Valve | Port Size: | 1/8'' |
|---|---|---|---|
| Thread Type: | G, NPT | Orifice Size: | 1mm To 3mm |
| Body Material: | Brass | Seal Material: | NBR, EPDM, FKM |
| Working Medium: | Water, Air, Oil, Gas, Steam, Etc | Working Medium Temperature Range: | NBR: -5 To +120 ºC, EPDM: -30 ℃ To +120℃, FKM: -30 ℃ To +150℃ |
| Working Pressure Range: | 0 To 10 Bar | Operation: | Direct Acting |
| Function: | 2 Way Normally Closed | Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| High Light: | CEME Solenoid Valve 5503,Brass Solenoid Valve 1/8'' NPT,2/2 Way Normally Closed Solenoid Valve |
||
5503 CEME Type 1/8'' NPT Brass Solenoid Valve 2/2 Way Normally Closed 24V 220V
Product Features:
1. Port Size: 1/8'' (G, NPT)
2. Orifice Size: 1mm to 3mm
3. Body Material: Brass
4. Seal Material: NBR, EPDM, FKM
5. Working Medium: Water, Air, Gas, Oil, Steam, etc
6. Working Medium Temperature Range: NBR: -5 to +120 ºC, EPDM: -30 ℃ to +120℃, FKM: -30 ℃ to +150℃
7. Working Pressure Range: 0 to 10 bar
8. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Dimension and Data of Solenoid Valve:
