| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 246AA |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Port Size: | 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'' | Orifice Size: | 12mm, 15mm, 20mm, 25mm, 32mm, 40mm, 50mm |
|---|---|---|---|
| Operation: | Diaphragm Pilot Operated | Body Material: | Brass |
| Working Medium: | Water | Seal Material: | NBR, EPDM, FKM |
| Pressure Range: | 0.05 To 1.6 MPa | Latching Coil Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz) |
| High Light: | Solenoid Valve For Fire Fighting System,Water Control Solenoid Valve,Manual Override Switch Solenoid Valve |
||
1'' Water Control Brass Solenoid Valve For Fire Fighting System
Product Features of Fire Fighting Solenoid Valve:
1. Working Medium: Water.
2. Working Pressure Range: 0.05 to 1.6 MPa
3. Medium Temperature Range: NBR (-10 to +80℃), EPDM (-30 to +120℃), FKM (-30 to +150℃)
4. Port Size: 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''
5. Orifice Size: 12mm, 15mm, 20mm, 25mm, 32mm, 40mm, 50mm
6. Body Material: Brass, Stainless Steel
7. Diaphragm Material: NBR, EPDM, FKM
8. Function: 2 Way Normally Closed
9. Operation: Diaphragm Pilot Operated
10. Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Technical Data of Fire Fighting Solenoid Valve:
Main Dimension of Fire Fighting Solenoid Valve:
Brando Factory Production Video of Solenoid Valves:
BRANDO Factory Production Picture of Solenoid Valves:
Packaging and Shiping of Brando Solenoid Valves:
|
|
|
| Internal Box | Carton | Pallet |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
