1'' Magnetic Latching Solenoid Valve For Water Air 6V 12V 24V DC

1'' Magnetic Latching Solenoid Valve For Water Air 6V 12V 24V DC

Product Features of Latching Brass Solenoid Valve:

1. Working Medium: Air, Water, etc.
2. Working Pressure Range: 0 to 0.8 MPa (See the parameter table below for details)
3. Medium Temperature Range: NBR (-10 to +80℃), EPDM (-30 to +120℃), FKM (-30 to +150℃)
4. Port Size: 3/8'', 1/2'', 3/4'', 1''
5. Orifice Size: 12mm, 15mm, 20mm, 25mm
6. Body Material: Brass, Stainless Steel
7. Seal Material: NBR, EPDM, FKM
8. Operation: Direct Lift Diaphragm
8. Latching Coil Voltage Option: 6VDC, 12VDC, 24VDC, Instant power-on time (0.3 to 0.5 sec)

Technical Data of Latching Brass Solenoid Valve:

Main Dimension of Latching Brass Solenoid Valve:

More Latching Solenoid Valves for you to choose:

Brando Factory Production Video of Solenoid Valves:

BRANDO Factory Production Picture of Solenoid Valves:

Packaging and Shiping of Brando Solenoid Valves:

Internal Box	Carton	Pallet

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
