2'' Water Fountain Brass Solenoid Valve IP68 Underwater 24V 220V

2'' Water Fountain Brass Solenoid Valve IP68 Underwater 24V 220V

  • 2'' Water Fountain Brass Solenoid Valve IP68 Underwater 24V 220V
2'' Water Fountain Brass Solenoid Valve IP68 Underwater 24V 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 46A-B
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Medium: Water Port Size: 1/2'', 3/4'', 1'', 1 1/4'' ,1 1/2'', 2''
Pipe Connection: Threaded Function: 2 Way Normally Closed
Operation: Direct Lifting Diaphragm Diaphragm Material: NBR, FKM, EPDM
Body Material: Brass, Stainless Steel Working Pressure Range: 0 To 0.5 MPa
Coil Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC Coil Protection Class: IP68, Waterproof
High Light:

Fountain Solenoid Valve 2''

,

Underwater Solenoid Valve 2''

,

Water Fountain Solenoid Valve

2'' Water Fountain Brass Solenoid Valve IP68 Underwater 24V 220V



BRANDO manufactures waterproof solenoid valve with IP68 protection class for underwater use. It can be used for 10 meters underwater. Available in Stainless Steel, Brass, Cast Steel and PVC material for your choice. Widely used in water fountain, SPA, swimming pool and any applications which require a waterproof solution.



1. Structure: Diaphragm Operated, Piston Operated
2. Function: Normally Closed or Normally Open
3. Body Material: Brass, Stainless Steel, Cast Steel, and PVC
4. Size Range: 1/8'', 1/4'', 3/8'', 1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2'', 3'', 4'', 5'', 6''
5. Connection Type: Threaded, Flanged
6. Seal Material: NBR, FKM, EPDM
7. Voltage.12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
8. Voltage Tolerance: +10%
9. Any special requirements, please consult us and we will help you resolve the issue and select the right valve!



Dimension of Fountain Solenoid Valve:

2'' Water Fountain Brass Solenoid Valve IP68 Underwater 24V 220V 0

Model
A
B
C
D
46A15
68
56
100
13.5
46A20
68
56
105
16.5
46A25
95
72
115
20.5
46A32
100
76
124
24.5
46A40
111
89
137
28
46A50
130
93
153
35



Technical Data of Fountain Solenoid Valve:

Model

46A15

46A20

46A25

46A32

46A40

46A50
Orifice Size
15
20
25
32
40
50
Port Size
1/2''
3/4''
1''
1 1/4''
1 1/2''
2''
Connection Type
Threaded
Medium
Water
Action
Direct Lifting Diaphragm
Function
2 Way Normally Closed
Body Material
Brass, Stainless Steel
Seal Material
NBR, FKM, EPDM
Pressure
Range
0 to 0.5 MPa
Temp. Range
NBR: -10 to +80℃
EPDM: -30 to +120℃
FKM: -30 to +150℃
Coil Voltages
AC: 24V, 120V, 240V (60Hz), 110V, 220V (50Hz)
DC: 12V, 24V
Coil Power
26VA, 13W
Protection Class
IP68, Waterproof
