Name: 1 1/4'' Flanged Electric Brass Solenoid Valve Water 24V DC 220V AC
Brand: Brando
SKU: UWF-35
Rating: 4.7 (144 reviews)

Home Products Brass Solenoid Valve

1 1/4'' Flanged Electric Brass Solenoid Valve Water 24V DC 220V AC

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	UWF-35

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	1 1/4''	Orifice Size:	35mm
Pipe Connection:	Flanged	Operation Mode:	2 Way Normally Closed
Action:	Direct Lifting Diaphragm	Working Fluids:	Air, Water, Oil, Gas
Body Material:	Brass	Seal Material:	NBR, FKM, EPDM
Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC	Pressure Range:	0 To 1 MPa
High Light:	1 1/4'' Water Solenoid Valve , 1 1/4'' Brass Solenoid Valve , Flange Water Solenoid Valve

1 1/4'' Flanged Electric Brass Solenoid Valve Water 24V DC 220V AC

Product Features:

1. Function: 2 Way Normally Closed, 2 Way Normally Open
2. Operation: Direct Lifting Diaphragm
3. Port Sizes: 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'', etc;
4. Orifice Sizes: 15mm, 20mm, 25mm, 35mm, 40mm, 50mm

5. Pipe Connection: Flanged
6. Working Medium: Water, Air, Gas, Oil, etc.

7. Valve Body Material: Brass, Stainless Steel
8. Valve Seal Material: NBR, EPDM, FKM;
9. Solenoid Coil Voltages: 12VDC 24VDC, 24VAC, 110VAC, 220VAC, etc;
10. Solenoid Coil Protection Class: IP65, IP67, Ex Proof, etc;

Technical Data of Solenoid Valve:

UWF Series (Brass)	UWF-15	UWF-20	UWF-25	UWF-35	UWF-40	UWF-50
SUWF Series (SS304)	SUWF-15	SUWF-20	SUWF-25	SUWF-35	SUWF-40	SUWF-50
Pipe Size	1/2''	3/4''	1''	1 1/4''	1 1/2''	2''
Orifice Size	16mm	20mm	25mm	35mm	40mm	50mm
Body Material	Brass, Stainless Steel
Diaphragm Material	NBR, FKM, EPDM
Fluid	Water, Air, Light Oil, Gas, Vacuum
Function	2 Way, Normally Closed
Action	Direct Liftng Diaphragm
Working Pressure	0 to 1 MPa
Fluid Temperature	-5 to +80℃ (NBR), -5 to +150℃ (FKM)
Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Main Dimension of Solenoid Valve:

1 1/4'' Flanged Electric Brass Solenoid Valve Water 24V DC 220V AC 0

UWF Series (Brass)	SUWF Series (SS304)	Orifice Size	H	L	D	D1	n-d
UWF-15	SUWF-15	16	145	115	95	65	4-φ14
UWF-20	SUWF-20	20	145	115	105	75	4-φ14
UWF-25	SUWF-25	25	166	135	110	85	4-φ14
UWF-35	SUWF-35	35	205	148	135	100	4-φ18
UWF-40	SUWF-40	40	218	160	145	110	4-φ18
UWF-50	SUWF-50	50	228	202	156	125	4-φ18
