1/4'' 3/8'' 1/2'' 2 Way NC Compact Brass Electric Solenoid Valve 24V 220V

1/4'' 3/8'' 1/2'' 2 Way NC Compact Brass Electric Solenoid Valve 24V 220V

  • 1/4'' 3/8'' 1/2'' 2 Way NC Compact Brass Electric Solenoid Valve 24V 220V
1/4'' 3/8'' 1/2'' 2 Way NC Compact Brass Electric Solenoid Valve 24V 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 5AA-B
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Port Size: 1/4'', 3/8'', 1/2'' Orifice Size: 6mm
Operation Mode: 2 Way, Normally Closed Operation: Direct Acting
Body Material: Brass Working Medium: Air, Water, Etc
Seal Material: NBR, FKM, EPDM, PTFE Pressure Range: 0 To 1.0 MPa
Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
High Light:

Compact Brass Solenoid Valve

,

2 Way Brass Solenoid Valve

,

1/2'' Brass Electric Solenoid Valve

1/4'' 3/8'' 1/2'' 2 Way NC Compact Brass Electric Solenoid Valve 24V 220V


Product Features of Brass Solenoid Valve:

1. Working Medium: Air, Water, etc.
2. Working Pressure Range: 0 to 1.0 MPa (See the parameter table below for details)
3. Medium Temperature Range: NBR (-10 to +80℃), EPDM (-30 to +120℃), FKM (-30 to +150℃), PTFE (-60 to +200℃)
4. Port Size: 1/4'', 3/8'', 1/2''
5. Orifice Size: 6mm
6. Body Material: Brass, Stainless Steel
7. Seal Material: NBR, EPDM, FKM, PTFE
8. Function: 2 Way Normally Closed, 2 Way Normally Open
9. Operation: Direct Acting
10. Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)



Technical Data of Brass Solenoid Valve:



2 Way Normally Closed

Model
Port Size
Orifice Size
Cv
Min Pressure
Max Pressure
Seal Material
Body Material
AC
DC
5AA
1/4''
6mm
0.8
0MPa
1.0MPa
1.0MPa
NBR
EPDM
FKM
PTFE
Brass
Stainless Steel
3/8''
1/2''



2 Way Normally Open

Model
Port Size
Orifice Size
Cv
Min Pressure
Max Pressure
Seal Material
Body Material
AC
DC
5BA
1/4''
6mm
0.8
0MPa
1.0MPa
1.0MPa
NBR
EPDM
FKM
PTFE
Brass
Stainless Steel
3/8''
1/2''


Main Dimension of Brass Solenoid Valve:

1/4'' 3/8'' 1/2'' 2 Way NC Compact Brass Electric Solenoid Valve 24V 220V 0
2 Way Normally Closed, 1/4'' Port Size
1/4'' 3/8'' 1/2'' 2 Way NC Compact Brass Electric Solenoid Valve 24V 220V 1
2 Way Normally Closed, 3/8'' & 1/2'' Port Size



Brando Factory Production Video of Solenoid Valves:



BRANDO Factory Production Picture of Solenoid Valves:

1/4'' 3/8'' 1/2'' 2 Way NC Compact Brass Electric Solenoid Valve 24V 220V 2



Packaging and Shiping of Brando Solenoid Valves:

1/4'' 3/8'' 1/2'' 2 Way NC Compact Brass Electric Solenoid Valve 24V 220V 3 1/4'' 3/8'' 1/2'' 2 Way NC Compact Brass Electric Solenoid Valve 24V 220V 4 1/4'' 3/8'' 1/2'' 2 Way NC Compact Brass Electric Solenoid Valve 24V 220V 5
Internal Box Carton Pallet
