Name: 2L-35 1 1/4'' Brass Steam Hot Water Solenoid Valve 12V 24V 110V 220V
Brand: Brando
SKU: 2L-35
Rating: 4.9 (114 reviews)

Home Products Brass Solenoid Valve

2L-35 1 1/4'' Brass Steam Hot Water Solenoid Valve 12V 24V 110V 220V

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2L-35

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Working Medium:	Steam, Hot Water	Port Size:	1 1/4''
Orifice Size:	30mm	Operation Mode:	2 Way Normally Closed
Operation:	Piston Pilot Operated	Body Material:	Brass
Seal Material:	PTFE	Working Temperature Range:	-20 To +185℃
Pressure Range:	0.1 To 1.5 MPa	Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
High Light:	1 1/4'' Steam Solenoid Valve , Hot Water Solenoid Valve 24V , Solenoid Valve 2L-35

2L-25 1'' DN25 Brass Steam Solenoid Valve High Temperature 24V 220V

Product Features of 2L series Steam Solenoid Valve:

1. Working Medium: Hot Water, Steam, etc
2. Working Pressure Range: 0.1 to 1.5 MPa
3. Seal Material: PTFE
4. Body Material: Brass, Stainless Steel
5. Port Size: 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''
6. Orifice Size: 17mm, 22mm, 30mm, 50mm
7. Operation: Piston Pilot Operated

8. Function: 2 Way Normally Closed
9. Coil Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data of 2L series Steam Solenoid Valve:

2L Series Model	2L-10	2L-15	2L-20	2L-25	2L-35	2L-40	2L-50
US Series Model	US-10	US-15	US-20	US-25	US-35	US-40	US-50
Orifice Size	17	17	17	22	30	30	50
Port Size	3/8''	1/2''	3/4''	1''	1-1/4''	1-1/2''	2''
Medium	Hot Water, Steam
Action	Piston Pilot Operated
Function	2 Way Normally Closed
Body Material	Brass, Stainless Steel
Seal Material	PTFE
Pressure Range	0.1 to 1.5 MPa
Temp. Range	-20 to +185℃
Coil Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Dimension of 2L series Steam Solenoid Valve:

2L-35 1 1/4'' Brass Steam Hot Water Solenoid Valve 12V 24V 110V 220V 0

US Series	2L Series	A	B	C	Port Size
US-10	2L-10	82	42	146	3/8''
US-15	2L-15				1/2''
US-20	2L-20				3/4''
US-25	2L-25	90	54	162	1''
US-35	2L-35	110	75	185	1 1/4''
US-40	2L-40	110	75	185	1 1/2''
US-50	2L-50	120	77	195	2''
