| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 1913CA-3-B |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Port Size: | 1/8'', 1/4'' | Orifice Size: | 1.6mm, 2.5mm, 3mm, 3.5mm, 4mm |
|---|---|---|---|
| Operation Mode: | 2 Way, Normally Closed | Operation: | Direct Acting |
| Body Material: | Brass | Working Medium: | Air, Water, Oil, Steam |
| Seal Material: | NBR, FKM, EPDM | Pressure Range: | 0 To 1.6 MPa |
| Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | ||
| High Light: | Solenoid Valve Group,Solenoid Valve Combination,Multi Way Solenoid Valve |
||
1/8'' 1/4'' Multi Way 3 Group Brass Solenoid Valve Combination 24VDC 220VAC
Product Features of Brass Solenoid Valve:
1. Working Medium: Air, Water, Steam, Oil etc.
2. Working Pressure Range: 0 to 1.6 MPa (See the parameter table below for details)
3. Medium Temperature Range: NBR (-10 to +80℃), EPDM (-30 to +120℃), FKM (-30 to +150℃)
4. Port Size: 1/8'', 1/4''
5. Orifice Size: 1.6mm, 2.5mm, 3mm, 3.5mm, 4mm
6. Body Material: Brass, Stainless Steel
7. Seal Material: NBR, EPDM, FKM
8. Function: 2 Way Normally Closed
9. Operation: Direct Acting
10. Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Technical Data of Brass Solenoid Valve:
Main Dimension of Brass Solenoid Valve Combination:
| 4 Group Solenoid Valve |
 |
| 5 Group Solenoid Valve |
|
Brando Factory Production Video of Solenoid Valves:
BRANDO Factory Production Picture of Solenoid Valves:
Packaging and Shiping of Brando Solenoid Valves:
|
|
|
| Internal Box | Carton | Pallet |
