1/2'' 3/4'' 1'' Brass Steam Solenoid Valve DN15 DN20 DN25 24V 220V

1/2'' 3/4'' 1'' Brass Steam Solenoid Valve DN15 DN20 DN25 24V 220V

  • 1/2'' 3/4'' 1'' Brass Steam Solenoid Valve DN15 DN20 DN25 24V 220V
1/2'' 3/4'' 1'' Brass Steam Solenoid Valve DN15 DN20 DN25 24V 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 26326AA
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Port Size: 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'' Orifice Size: 15mm, 20mm, 25mm, 32mm, 40mm, 50mm
Operation Mode: 2 Way, Normally Closed Operation: Pilot Piston Operated
Body Material: Brass Seal Material: PTFE, FKM
Working Medium: Steam, Hot Water, High Temp Liquid, Oil, Etc Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Pressure Range: 0.3 To 10 Bar Temperature Range: 0 To +180℃
High Light:

Steam Solenoid Valve DN15

,

Steam Solenoid Valve DN20

,

Steam Solenoid Valve DN25

1/2'' 3/4'' 1'' Brass Steam Solenoid Valve DN15 DN20 DN25 24V 220V


Product Features of Steam Solenoid Valve:

1. Working Medium: Hot Water, Steam, Oil, etc
2. Working Pressure Range: 0.3 to 10 Bar
3. Seal Material: PTFE, FKM
4. Body Material: Stainless Steel, Brass
5. Port Size: 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''
6. Orifice Size: 12mm, 15mm, 20mm, 25mm, 32mm, 40mm, 50mm
7. Operation: PIston Pilot Operated
8. Coil Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)



Technical Data of Steam Solenoid Valve:

Model
Port Size
Orifice Size
Cv
Min Pressure
Max Pressure
Seal Material
Body Material
AC
DC
Normally Closed
26326AA12
3/8''
12mm
4.5
0.03MPa
1.0MPa
1.0MPa
PTFE
FKM
Brass
Stainless Steel
26326AA15
1/2''
15mm
4.5
26326AA20
3/4''
20mm
9.3
26326AA25
1''
25mm
12
26326AA32
1 1/4''
32mm
24
26326AA40
1 1/2''
40mm
29
26326AA50
2''
50mm
48
Normally Open
26326AB12
3/8''
12mm
4.5
0.03MPa
1.0MPa
1.0MPa
PTFE
FKM
Brass
Stainless Steel
26326AB15
1/2''
15mm
4.5
26326AB20
3/4''
20mm
9.3
26326AB25
1''
25mm
12
26326AB32
1 1/4''
32mm
24
26326AB40
1 1/2''
40mm
29
26326AB50
2''
50mm
48


Main Dimension of Steam Solenoid Valve:

1/2'' 3/4'' 1'' Brass Steam Solenoid Valve DN15 DN20 DN25 24V 220V 0 1/2'' 3/4'' 1'' Brass Steam Solenoid Valve DN15 DN20 DN25 24V 220V 1



Model
A
B
C
D
26326AA15
70
60
150
22
26326AA20
80
65
160
25
26326AA25
100
80
170
30
26326AA32
140
80
210
30
26326AA40
140
110
200
43
26326AA50
140
110
205
48
