Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V

Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V

  • Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V
Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: D971
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Butterfly Power: Electric
Body Material: Cast Iron, Cast Steel Seal Material: Rubber, PTFE
Working Medium: Neutral Gas, Air Orifice Size: DN40 To DN300
High Light:

Electric Wafer Butterfly Valve

,

4'' Butterfly Valve With Electric Actuator

,

4'' Electric Actuated Butterfly Valve

Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V



BRANDO’s range of electrically controlled butterfly valves, which are used to control the flow of a media remotely. They can have either a lug or wafer connection style. The actuator either opens or closes the valve with an electrical current, but doesn’t require energy to stay in that state. The butterfly valve has a disc that rotates with the actuator to open or close the butterfly valve. The butterfly valve design allows for good sealing properties, durability, and reliability for your application. Electrical actuators are easily installed and wired into an existing system. There are various housings, seals, and sizes of electrically controlled butterfly valves to allow you to find the right one for your application.



Technical Data of Electric Butterfly Valve:

Pneumatic Buterfly Valve
Electric Butterfly Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Manufacturing Standard: GB, ISO, ANSI, BS, DIN


Main Dimension of Electric Butterfly Valve:

Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 0

Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 1



More Electric Actuator Valves for you to choose:

Electric Ball Valves
Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 2 Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 3 Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 4 Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 5
Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 6 Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 7 Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 8 Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 9
Electric Butterfly Valves
Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 10 Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 11 Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 12 Cast Steel Electric Actuator Wafer Butterfly Valve 4'' DN100 24V 220V 13
