| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | Q984 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 50000 pcs per month |
| Way Number: | 3 Way | Port Size: | 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'' |
|---|---|---|---|
| Structure: | Ball | Power: | Electric |
| Pipe Connection: | Tri Clamp | Body Material: | Cast Steel, SS304, SS316 |
| Seal Material: | PTFE, TFM | Medium Temperature: | PTFE: -20 To +180℃, TFM: -30 To +230℃ |
| Working Medium: | Neutral Gas, Air | ||
| High Light: | Electric 3 Way Ball Valve,3 Way Ball Valve With Electric Actuator,3 Way Electric Actuated Ball Valve |
||
3 Way Electric Actuator Tri Clamp Ball Valve Stainless Steel 24V 220V
Ball valves can be combined with a pneumatic actuator (pneumatic ball valves) or an electric actuator (electric ball valves) for automation and/or for controlling remotely. Depending on the application, automating with a pneumatic actuator vs an electric one may be more advantageous, or vice-versa.
Electric actuators convert electrical energy into rotary force by the use of an electric motor to turn the ball valve through 90 degrees. They are energy-efficient, clean, and a quiet method of valve control. The electric motor can be powered by an alternating current (AC) or a direct current (DC). It is housed in a robust, compact housing that also contains other components of the actuator such as gearings, limit switches, wiring, etc. The whole assembly is connected to a valve through a compatible connection interface.
Technical Data of Electric Ball Valve:
Main Dimension of Electric Ball Valve:
Flow Direction of 3 Way Electric Actuator Ball Valve:
More Electric Actuator Valves for you to choose:
| Electric Ball Valves | |||
|
|
|
|
|
|
|
|
| Electric Butterfly Valves | |||
|
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
