| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | Q914 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 50000 pcs per month |
| Way Number: | 3 Way | Port Size: | 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'' |
|---|---|---|---|
| Structure: | Ball | Power: | Electric |
| Pipe Connection: | Female Thread | Body Material: | Cast Steel, SS304, SS316 |
| Seal Material: | PTFE, TFM | Medium Temperature: | PTFE: -20 To +180℃, TFM: -30 To +230℃ |
| Working Medium: | Neutral Gas, Air | ||
| High Light: | 3 Way Electric Actuated Ball Valve,3 Way Ball Valve With Electric Actuator,Electric Tee Ball Valve |
||
1'' Stainless Steel 3 Way Ball Valve With Electric Actuator 24V 220V
Electric actuated ball valves, also known as motorized ball valves or rotary ball valves, are the most popular choice for ball valve automation. These products use an electric motor to operate the ball valve and control the flow of media.
Here's a breakdown of the components:
Electric: Refers to the use of voltage to power the actuator.
Actuator: The component that is used to automate control of the ball valve. This uses voltage to power the valve on/off.
Ball Valve: A quarter-turn on/off valve that controls the flow of liquid or gas media via a pivoting ball.
Technical Data of Electric Ball Valve:
Main Dimension of Electric Ball Valve:
Flow Direction of 3 Way Electric Actuator Ball Valve:
More Electric Actuator Valves for you to choose:
| Electric Ball Valves | |||
|
|
|
|
|
|
|
|
| Electric Butterfly Valves | |||
|
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
