1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304

1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304

  • 1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304
1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q911
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball Power: Electric
Pipe Connection: Female Thread Body Material: Stainless Steel (304, 316)
Seal Material: PTFE, TFM Working Medium: Neutral Gas, Air
Port Size: 1/2'' To 4''
High Light:

Electric Actuator Ball Valve

,

1'' Electric Ball Valve

,

Electric Actuated Ball Valve

1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304




Ball valves can be combined with a pneumatic actuator (pneumatic ball valves) or an electric actuator (electric ball valves) for automation and/or for controlling remotely. Depending on the application, automating with a pneumatic actuator vs an electric one may be more advantageous, or vice-versa.



Electric actuators convert electrical energy into rotary force by the use of an electric motor to turn the ball valve through 90 degrees. They are energy-efficient, clean, and a quiet method of valve control. The electric motor can be powered by an alternating current (AC) or a direct current (DC). It is housed in a robust, compact housing that also contains other components of the actuator such as gearings, limit switches, wiring, etc. The whole assembly is connected to a valve through a compatible connection interface.



Technical Data of Electric Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Main Dimension of Electric Ball Valve:

1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 0

1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 1



More Electric Actuator Valves for you to choose:

Electric Ball Valves
1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 2 1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 3 1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 4 1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 5
1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 6 1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 7 1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 8 1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 9
Electric Butterfly Valves
1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 10 1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 11 1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 12 1'' DN25 3 Piece Electric Actuator Ball Valve Stainless Steel 304 13



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
