Pneumatic Actuated Butterfly Valve With Solenoid Valve Limit Switch

Pneumatic Actuated Butterfly Valve With Solenoid Valve Limit Switch

  • Pneumatic Actuated Butterfly Valve With Solenoid Valve Limit Switch
Pneumatic Actuated Butterfly Valve With Solenoid Valve Limit Switch
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: D671
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Product Name: Pneumatic Butterfly Valve Orifice Size: DN40 To DN300
Connection Type: Wafer Body Material: Cast Iron, Cast Steel
Seal Material: Rubber Working Medium: Neutral Gas, Air
High Light:

Pneumatic Actuated Butterfly Valve

,

Pneumatic Operated Butterfly Valve

,

Pneumatic Actuator Butterfly Valve

Pneumatic Actuated Butterfly Valve With Solenoid Valve Limit Switch



Mechanism of Pneumatic Actuated Butterfly Valve:

Pneumatic Butterfly valve works on a simple mechanism and easy to use so it has low maintenance, these valves are fitted in mid of fluid flow. There is a disc connected to a center rod, which rotates the disc quarterly to pass through to open and close. This metal disc called Butterfly, rotates a quarter turn to allow fluid to pass indefinitely and so on the slow opening valve will reduce the flow, and the turning the disc to close the valve and flow. This valve is operated by pressurized air which is controlled by a pneumatic actuator that is fixed on it. So there is nobody who needs to operate but the pneumatic actuator operates this valve too fast and easily with the lowest cost and safety.



Technical Data of Pneumatic Butterfly Valve:

Pneumatic Butterfly Valve
Electric Butterfly Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Main Dimension of Pneumatic Butterfly Valve:

Pneumatic Actuated Butterfly Valve With Solenoid Valve Limit Switch 0

Pneumatic Actuated Butterfly Valve With Solenoid Valve Limit Switch 1
