DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel

DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel

  • DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel
DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q614
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball Power: Pneumatic
Pipe Connection: Female Thread Body Material: Cast Steel, SS304, SS316
Seal Material: PTFE, TFM Working Medium: Neutral Gas, Air
Port Size: 1/2'' To 2'' Way Number: 3 Way
Flow Direction: L Pattern, T Pattern Medium Temperature: PTFE: -20 To +180℃, TFM: -30 To +230℃
High Light:

Pneumatic Three Way Ball Valve

,

Air Actuated Ball Valve

,

Pneumatic 3 Way Ball Valve

DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel



A pneumatic actuated ball valve uses compressed air to automate the control of media. Pneumatic actuated ball valves don’t rely on a motor, but they do require electricity when paired with an integral pilot or solenoid valve.



Here’s a breakdown of the components:

Pneumatic: Refers to the use of pressurized air or gas to create energy.
Actuator: The component that is used to automate control of the ball valve.
Ball Valve: A quarter-turn on/off valve that controls flow of media via a pivoting ball



Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Flow Direction of 3 Way Pneumatic Ball Valve:

DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 0



Main Dimension of Pneumatic Ball Valve:

DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 1

DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 2



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 3 DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 4 DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 5 DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 6
DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 7 DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 8 DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 9 DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 10
Pneumatic Butterfly Valves
DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 11 DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 12 DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 13 DN25 1'' Air Actuated Pneumatic Three Way Ball Valve Stainless Steel 14



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
