DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel

DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel

  • DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel
DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: JZF-DN20-F
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Port Size: 3/4'' Port Connections: Flanged
Orifice Size: 20mm Working Fluids: Netral And Aggressive Liquid, Gas
Body Material: SS304, SS316 Seal Material: PTFE
Working Pressure Range: 0.4 To 0.8 MPa Max. Working Pressure Range: 1.6 MPa
High Light:

Pneumatic Angle Seat Valve Stainless Steel

,

Y Type Pneumatic Angle Seat Valve

,

Pneumatic Angle Seat Valve With Solenoid Valve

DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel



Pneumatic angle seat valve is a general switch in the automatic control system which are suitable in demanding applications such as steam, water and aggressive media. They are especially suited for vacuum and fast acting applications that require a long service life. It is widely used in printing, dyeing, bleaching, food, washing, chemical, water treatment, pharmacy and other automatic machinery and equipment. It is featured with water hammer protection, noise-free, reliable sealing performance.



Main Dimension of Angle Seat Valve:



Stainless Steel Body With Plastic Actuator

                                  DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel 0

DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel 1



Technical Data of Angle Seat Valve:

Medium Temperature
-10 to +180℃
Ambient Temperature
-10 to +60℃
Max. Working Pressure Range
1.6 MPa
Working Medium
Netral and Aggressive Liquid, Gas
Working Pressure
0.4 to 0.8 MPa
Body Material
SS304, SS316
Seal Material
PTFE
Connection Size
1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2'', 2-1/2'', 3'', 4''
Port Connections
Threaded, Flanged, Welded, Clamp
Nominal Diameter
DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100
Safety setting in case of power failure
Normally Closed, Normally Open



Angle Seat Valve Disassembly Display:

DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel 2



Brando Factory Valve Production:



More Angle Seat Valves for you to choose:

DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel 3 DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel 4 DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel 5
DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel 6 DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel 7 DN20 3/4'' Flanged Y Type Pneumatic Angle Seat Valve Stainless Steel 8



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
